nodeplayer-addon 0.3.0 → 0.3.1

package/docs/vue-frontend.md

@@ -0,0 +1,330 @@
+在快速集成中，我们使用官方推荐的Electron Forge创建程序。可以用来开发react但是需要很多配置，我们在这个例子中换一个更简单的脚手架： [create-electron](https://www.npmjs.com/package/%40quick-start/create-electron)
+
+## 1.创建项目
+```bash
+npm create @quick-start/electron
+```
+
+```bash
+> npx
+> "create-electron"
+
+✔ Project name: … electron-app-vue
+✔ Select a framework: › vue
+✔ Add TypeScript? … No / Yes
+✔ Add Electron updater plugin? … No / Yes
+✔ Enable Electron download mirror proxy? … No / Yes
+
+Scaffolding project in /Users/aliang/electron-app-vue...
+
+Done. Now run:
+
+  cd electron-app-vue
+  npm install
+  npm run dev
+```
+编辑器打开项目，可以看到目录结构如下
+![](https://www.nodemedia.cn/wp-content/uploads/2026/06/QQ20260601-170644.png)
+
+## 2.安装扩展
+执行命令
+```bash
+npm i nodeplayer-addon
+```
+
+## 3.编辑 src/main/index.js 文件
+```js
+import { app, shell, BrowserWindow, ipcMain } from 'electron'
+import { join } from 'path'
+import { electronApp, optimizer, is } from '@electron-toolkit/utils'
+import icon from '../../resources/icon.png?asset'
+import NodePlayer from 'nodeplayer-addon'
+
+let mainWindow = null
+
+function createWindow() {
+  mainWindow = new BrowserWindow({
+    width: 1024,
+    height: 768,
+    show: false,
+    autoHideMenuBar: true,
+    ...(process.platform === 'linux' ? { icon } : {}),
+    webPreferences: {
+      preload: join(__dirname, '../preload/index.js'),
+      sandbox: false
+    }
+  })
+
+  mainWindow.on('ready-to-show', () => {
+    mainWindow.show()
+  })
+
+  mainWindow.webContents.setWindowOpenHandler((details) => {
+    shell.openExternal(details.url)
+    return { action: 'deny' }
+  })
+
+  if (is.dev && process.env['ELECTRON_RENDERER_URL']) {
+    mainWindow.loadURL(process.env['ELECTRON_RENDERER_URL'])
+  } else {
+    mainWindow.loadFile(join(__dirname, '../renderer/index.html'))
+  }
+}
+
+app.whenReady().then(() => {
+  electronApp.setAppUserModelId('com.electron')
+
+  app.on('browser-window-created', (_, window) => {
+    optimizer.watchWindowShortcuts(window)
+  })
+
+  createWindow()
+
+  NodePlayer.registerIpc(ipcMain, {
+    getWindow: () => mainWindow,
+    licensePath: app.isPackaged
+      ? join(process.resourcesPath, 'license.dat')
+      : join(__dirname, '../../license.dat')
+  })
+
+  app.on('activate', function () {
+    if (BrowserWindow.getAllWindows().length === 0) createWindow()
+  })
+})
+
+app.on('window-all-closed', () => {
+  if (process.platform !== 'darwin') {
+    app.quit()
+  }
+})
+
+```
+
+## 4. 编辑src/preload/index.js
+```js
+import { contextBridge, ipcRenderer } from 'electron'
+import { electronAPI } from '@electron-toolkit/preload'
+
+const playerAPI = {
+  createPlayer: (id) => ipcRenderer.invoke('player:create', id),
+  startPlayer: (id, url) => ipcRenderer.invoke('player:start', id, url),
+  stopPlayer: (id) => ipcRenderer.invoke('player:stop', id),
+  destroyPlayer: (id) => ipcRenderer.invoke('player:destroy', id),
+  startRecord: (id, filePath) => ipcRenderer.invoke('player:startRecord', id, filePath),
+  stopRecord: (id) => ipcRenderer.invoke('player:stopRecord', id),
+  // 截图：将渲染进程生成的 JPG base64 数据保存到指定路径（默认由主进程自动生成）
+  saveScreenshot: (id, outputPath, base64Data) => ipcRenderer.invoke('player:screenshot', id, outputPath, base64Data),
+  // 预探测：在创建播放器前分析 URL（连接性 / 编码 / 分辨率 / 首帧截图）
+  getMediaInfo: (url) => ipcRenderer.invoke('player:getMediaInfo', url),
+
+  onEvent: (id, callback) => {
+    const channel = `player:event:${id}`
+    const handler = (_event, data) => callback(data)
+    ipcRenderer.on(channel, handler)
+    return () => ipcRenderer.removeListener(channel, handler)
+  },
+
+  onInfo: (id, callback) => {
+    const channel = `player:info:${id}`
+    const handler = (_event, info) => callback(info)
+    ipcRenderer.on(channel, handler)
+    return () => ipcRenderer.removeListener(channel, handler)
+  },
+
+  onData: (id, callback) => {
+    const channel = `player:data:${id}`
+    const handler = (_event, data) => callback(data)
+    ipcRenderer.on(channel, handler)
+    return () => ipcRenderer.removeListener(channel, handler)
+  }
+}
+
+if (process.contextIsolated) {
+  try {
+    contextBridge.exposeInMainWorld('electron', electronAPI)
+    contextBridge.exposeInMainWorld('electronAPI', playerAPI)
+  } catch (error) {
+    console.error(error)
+  }
+} else {
+  window.electron = electronAPI
+  window.electronAPI = playerAPI
+}
+
+```
+
+## 5.创建播放组件src/renderer/src/components/VideoPlayerView.vue
+```vue
+<script setup>
+import { ref, shallowRef } from 'vue'
+import VideoPlayer from 'nodeplayer-addon/video-player'
+
+const url = ref('rtsp://')
+const status = ref('')
+const playing = ref(false)
+
+const videoRef = ref(null)
+const playerRef = shallowRef(null)
+
+async function handlePlay() {
+  if (!url.value.trim()) return
+
+  const video = videoRef.value
+  if (!video) return
+
+  const player = new VideoPlayer(video, 'player-1')
+
+  const EVENT_STATUS = {
+    1000: 'Connecting...', 1001: 'Connected', 1002: 'Connection failed',
+    1003: 'Reconnecting...', 1004: 'Disconnected', 1005: 'Network error',
+    1006: 'Connection timeout', 3001: 'Recording...',
+  }
+
+  player.on('event', (code, msg) => {
+    if (code in EVENT_STATUS) status.value = msg ? `${EVENT_STATUS[code]}: ${msg}` : EVENT_STATUS[code]
+  })
+  player.on('error', (err) => { status.value = err.message })
+
+  playerRef.value = player
+  playing.value = true
+  await player.start(url.value.trim())
+}
+
+async function handleStop() {
+  const player = playerRef.value
+  if (player) {
+    await player.stop()
+    playerRef.value = null
+  }
+  playing.value = false
+  status.value = ''
+}
+
+async function handleScreenshot() {
+  const player = playerRef.value
+  if (!player) return
+  const r = await player.saveScreenshot()
+  status.value = r.success ? '截图已保存：' + r.path : (r.error || '截图失败')
+}
+
+function onKeydown(e) {
+  if (e.key === 'Enter' && !playing.value) handlePlay()
+}
+</script>
+
+<template>
+  <div class="player-container">
+    <div class="player-toolbar">
+      <input
+        type="text"
+        class="url-input"
+        :value="url"
+        :disabled="playing"
+        placeholder="rtsp:// or rtmp://"
+        @input="url = $event.target.value"
+        @keydown="onKeydown"
+      />
+      <button v-if="!playing" class="btn btn-play" :disabled="!url.trim()" @click="handlePlay">
+        ▶ Play
+      </button>
+      <button v-else class="btn btn-stop" @click="handleStop">■ Stop</button>
+      <button v-if="playing" class="btn btn-screenshot" @click="handleScreenshot">截图</button>
+    </div>
+
+    <div class="player-video-wrapper">
+      <video ref="videoRef" class="player-video" autoplay muted playsinline />
+      <div v-if="status" class="player-status">{{ status }}</div>
+    </div>
+  </div>
+</template>
+```
+
+## 6.加载组件 src/renderer/src/App.vue
+```vue
+<script setup>
+import Versions from './components/Versions.vue'
+import VideoPlayerView from './components/VideoPlayerView.vue'
+</script>
+
+<template>
+  <div class="app">
+    <header class="app-header">
+      <h1>NodePlayer</h1>
+    </header>
+    <main class="app-main">
+      <VideoPlayerView />
+    </main>
+    <footer class="app-footer">
+      <Versions />
+    </footer>
+  </div>
+</template>
+```
+
+## 运行效果
+![](https://www.nodemedia.cn/wp-content/uploads/2026/06/QQ20260601-171000.jpg)
+
+## 7. 更多功能
+
+上面的示例只演示了「播放 / 停止 / 截图」。`registerIpc` 实际在主进程注册了更多能力，下面按需选用。
+
+### 事件码参考
+
+播放器通过 `player.on('event', (code, msg) => {})` 推送事件，常用码如下：
+
+| 范围 | code | 含义 |
+|------|------|------|
+| 连接 | 1000 | 正在连接 |
+|      | 1001 | 已连接 |
+|      | 1002 | 连接失败 |
+|      | 1003 | 重连中 |
+|      | 1004 | 已断开 |
+|      | 1005 | 网络错误 |
+|      | 1006 | 连接超时 |
+| 录像 | 3001 | 录像开始 |
+|      | 3002 | 录像停止 |
+|      | 3003 | 录像错误 |
+
+> 流的编码、分辨率、采样率等参数通过 `player.on('info', (info) => {})` 单独推送，不走 `event`。
+
+### 流预探测（getMediaInfo）
+
+在加入播放列表前，可先探测地址是否可达、获取音视频参数并截取首帧预览图，整个过程不依赖任何播放器实例：
+
+```js
+// preload.js 已暴露：window.electronAPI.getMediaInfo(url)
+const info = await window.electronAPI.getMediaInfo('rtsp://...')
+
+if (!info.success) {
+  console.warn('探测失败：', info.error)
+} else {
+  const { video, audio, screenshot } = info.info
+  console.log(`视频：${video.width}x${video.height}（codecId=${video.codecId}）`)
+  console.log(`音频：采样率=${audio.sampleRate}，声道=${audio.channels}`)
+  if (screenshot) {
+    // screenshot 为 MJPEG 二进制 Buffer（base64 后可直接作为 <img> src）
+  }
+}
+```
+
+### 截图
+
+`VideoPlayer` 提供两种截图方式，均在**流就绪后**调用：
+
+- `player.saveScreenshot(outputPath?, quality?)` → 通过 IPC 将 JPG 写入磁盘，返回 `{ success, path }`，路径省略时由主进程自动生成
+
+```js
+// 直接预览（不落盘）
+const dataUrl = player.captureScreenshot(0.9)
+if (dataUrl) snapshotImg.src = dataUrl
+
+// 保存到文件
+const r = await player.saveScreenshot()
+if (r.success) console.log('已保存：', r.path)
+```
+
+## 联系客服索取demo源码
+- QQ: 281269007
+- Email: service@nodemedia.cn

package/package.json

@@ -1,6 +1,6 @@
 {
   "name": "nodeplayer-addon",
-  "version": "0.3.0",
+  "version": "0.3.1",
   "description": "An Electron native player addon, support RTSP and RTMP",
   "main": "dist/index.cjs",
   "module": "dist/index.mjs",
@@ -18,15 +18,16 @@
   },
   "files": [
     "dist",
+    "docs",
     "prebuilds",
-    "SKILL.md"
+    "README.md"
   ],
   "scripts": {
-    "test": "echo \"Error: no test specified\" && exit 1"
+    "test": "exit 0"
   },
   "repository": {
     "type": "git",
-    "url": "git+https://github.com/illuspas/nodeplayer-addon.git"
+    "url": "git+https://github.com/NodeMedia/nodeplayer-addon.git"
   },
   "keywords": [
     "electron",
@@ -40,7 +41,7 @@
   "license": "",
   "type": "commonjs",
   "bugs": {
-    "url": "https://github.com/illuspas/nodeplayer-addon/issues"
+    "url": "https://github.com/NodeMedia/nodeplayer-addon/issues"
   },
-  "homepage": "https://github.com/illuspas/nodeplayer-addon#readme"
+  "homepage": "https://github.com/NodeMedia/nodeplayer-addon#readme"
 }
