tracerlab 0.1.5__tar.gz

tracerlab-0.1.5/.gitignore

@@ -0,0 +1,7 @@
+.venv/
+__pycache__/
+.pytest_cache/
+.ruff_cache/
+*.pyc
+.DS_Store
+dist/

tracerlab-0.1.5/LICENSE

@@ -0,0 +1,21 @@
+MIT License
+
+Copyright (c) 2026 Atharv Santosh
+
+Permission is hereby granted, free of charge, to any person obtaining a copy
+of this software and associated documentation files (the "Software"), to deal
+in the Software without restriction, including without limitation the rights
+to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+copies of the Software, and to permit persons to whom the Software is
+furnished to do so, subject to the following conditions:
+
+The above copyright notice and this permission notice shall be included in all
+copies or substantial portions of the Software.
+
+THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
+AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
+SOFTWARE.

tracerlab-0.1.5/PKG-INFO

@@ -0,0 +1,82 @@
+Metadata-Version: 2.5
+Name: tracerlab
+Version: 0.1.5
+Summary: MCP server for Cisco Packet Tracer 9. Build, configure and verify networks from an AI agent.
+Project-URL: Homepage, https://github.com/atharv-santosh/tracerlab
+Project-URL: Repository, https://github.com/atharv-santosh/tracerlab
+Project-URL: Issues, https://github.com/atharv-santosh/tracerlab/issues
+Author-email: Atharv Santosh <atharvsantosh1@gmail.com>
+License: MIT
+License-File: LICENSE
+Keywords: automation,ccna,cisco,ios,mcp,networking,packet-tracer
+Classifier: Development Status :: 4 - Beta
+Classifier: Intended Audience :: Education
+Classifier: Intended Audience :: System Administrators
+Classifier: License :: OSI Approved :: MIT License
+Classifier: Programming Language :: Python :: 3.10
+Classifier: Programming Language :: Python :: 3.11
+Classifier: Programming Language :: Python :: 3.12
+Classifier: Programming Language :: Python :: 3.13
+Classifier: Topic :: Education
+Classifier: Topic :: System :: Networking
+Requires-Python: >=3.10
+Requires-Dist: mcp<3,>=2.3
+Description-Content-Type: text/markdown
+
+# Tracerlab
+
+MCP server for Cisco Packet Tracer 9. Lets Claude Code (or any MCP client) build networks in a running Packet Tracer: add devices, cable them, push IOS configs, address everything, set up routing, ping, and find what's broken. It can also read and write .pkt files without Packet Tracer open.
+
+![Building a 3 router OSPF ring, cabling it, addressing it and pinging across it](https://raw.githubusercontent.com/atharv-santosh/tracerlab/main/docs/demo.gif)
+
+Twelve devices, twelve cables, OSPF across the ring and 6/6 pings, from one prompt.
+
+There are also some ready-made labs (router on a stick, OSPF/EIGRP/RIP topologies, NAT, HSRP, EtherChannel, IPv6) that build in one call.
+
+## Install
+
+Needs [uv](https://docs.astral.sh/uv/) and Packet Tracer 9.
+
+Register the server with your MCP client:
+
+```
+claude mcp add packet-tracer -- uvx --from tracerlab packet-tracer-mcp
+```
+
+Cursor (`~/.cursor/mcp.json`), VS Code (`.vscode/mcp.json`) and Codex take the same command:
+
+```json
+{
+  "mcpServers": {
+    "packet-tracer": { "command": "uvx", "args": ["--from", "tracerlab", "packet-tracer-mcp"] }
+  }
+}
+```
+
+Then install the Packet Tracer side once:
+
+```
+uvx tracerlab install-extension
+```
+
+Restart Packet Tracer and answer Yes when it asks about the new script module. A small "PT-MCP Bridge"
+window shows up and goes green once the MCP server is running.
+
+If something isn't connecting, run `uvx tracerlab doctor`.
+
+## Use
+
+Open Packet Tracer, start Claude Code and ask for things like:
+
+- build a 3 router OSPF ring with a PC on each LAN and ping everything
+- set up router on a stick with VLANs 10, 20, 30 and DHCP
+- what's wrong with this network
+- show me the running config on R1
+
+`examples/enterprise-two-site.pkt` is a bigger network built entirely through the tools.
+
+## Tests
+
+```
+uv run pytest
+```

tracerlab-0.1.5/README.md

@@ -0,0 +1,57 @@
+# Tracerlab
+
+MCP server for Cisco Packet Tracer 9. Lets Claude Code (or any MCP client) build networks in a running Packet Tracer: add devices, cable them, push IOS configs, address everything, set up routing, ping, and find what's broken. It can also read and write .pkt files without Packet Tracer open.
+
+![Building a 3 router OSPF ring, cabling it, addressing it and pinging across it](https://raw.githubusercontent.com/atharv-santosh/tracerlab/main/docs/demo.gif)
+
+Twelve devices, twelve cables, OSPF across the ring and 6/6 pings, from one prompt.
+
+There are also some ready-made labs (router on a stick, OSPF/EIGRP/RIP topologies, NAT, HSRP, EtherChannel, IPv6) that build in one call.
+
+## Install
+
+Needs [uv](https://docs.astral.sh/uv/) and Packet Tracer 9.
+
+Register the server with your MCP client:
+
+```
+claude mcp add packet-tracer -- uvx --from tracerlab packet-tracer-mcp
+```
+
+Cursor (`~/.cursor/mcp.json`), VS Code (`.vscode/mcp.json`) and Codex take the same command:
+
+```json
+{
+  "mcpServers": {
+    "packet-tracer": { "command": "uvx", "args": ["--from", "tracerlab", "packet-tracer-mcp"] }
+  }
+}
+```
+
+Then install the Packet Tracer side once:
+
+```
+uvx tracerlab install-extension
+```
+
+Restart Packet Tracer and answer Yes when it asks about the new script module. A small "PT-MCP Bridge"
+window shows up and goes green once the MCP server is running.
+
+If something isn't connecting, run `uvx tracerlab doctor`.
+
+## Use
+
+Open Packet Tracer, start Claude Code and ask for things like:
+
+- build a 3 router OSPF ring with a PC on each LAN and ping everything
+- set up router on a stick with VLANs 10, 20, 30 and DHCP
+- what's wrong with this network
+- show me the running config on R1
+
+`examples/enterprise-two-site.pkt` is a bigger network built entirely through the tools.
+
+## Tests
+
+```
+uv run pytest
+```

tracerlab-0.1.5/npm/README.md

@@ -0,0 +1,57 @@
+# Tracerlab
+
+MCP server for Cisco Packet Tracer 9. Lets Claude Code (or any MCP client) build networks in a running Packet Tracer: add devices, cable them, push IOS configs, address everything, set up routing, ping, and find what's broken. It can also read and write .pkt files without Packet Tracer open.
+
+![Building a 3 router OSPF ring, cabling it, addressing it and pinging across it](https://raw.githubusercontent.com/atharv-santosh/tracerlab/main/docs/demo.gif)
+
+Twelve devices, twelve cables, OSPF across the ring and 6/6 pings, from one prompt.
+
+There are also some ready-made labs (router on a stick, OSPF/EIGRP/RIP topologies, NAT, HSRP, EtherChannel, IPv6) that build in one call.
+
+## Install
+
+Needs [uv](https://docs.astral.sh/uv/) and Packet Tracer 9.
+
+Register the server with your MCP client:
+
+```
+claude mcp add packet-tracer -- uvx --from tracerlab packet-tracer-mcp
+```
+
+Cursor (`~/.cursor/mcp.json`), VS Code (`.vscode/mcp.json`) and Codex take the same command:
+
+```json
+{
+  "mcpServers": {
+    "packet-tracer": { "command": "uvx", "args": ["--from", "tracerlab", "packet-tracer-mcp"] }
+  }
+}
+```
+
+Then install the Packet Tracer side once:
+
+```
+uvx tracerlab install-extension
+```
+
+Restart Packet Tracer and answer Yes when it asks about the new script module. A small "PT-MCP Bridge"
+window shows up and goes green once the MCP server is running.
+
+If something isn't connecting, run `uvx tracerlab doctor`.
+
+## Use
+
+Open Packet Tracer, start Claude Code and ask for things like:
+
+- build a 3 router OSPF ring with a PC on each LAN and ping everything
+- set up router on a stick with VLANs 10, 20, 30 and DHCP
+- what's wrong with this network
+- show me the running config on R1
+
+`examples/enterprise-two-site.pkt` is a bigger network built entirely through the tools.
+
+## Tests
+
+```
+uv run pytest
+```

tracerlab-0.1.5/pyproject.toml

@@ -0,0 +1,52 @@
+[project]
+name = "tracerlab"
+version = "0.1.5"
+description = "MCP server for Cisco Packet Tracer 9. Build, configure and verify networks from an AI agent."
+readme = "README.md"
+requires-python = ">=3.10"
+license = { text = "MIT" }
+authors = [{ name = "Atharv Santosh", email = "atharvsantosh1@gmail.com" }]
+keywords = ["mcp", "packet-tracer", "cisco", "networking", "ccna", "ios", "automation"]
+dependencies = ["mcp>=2.3,<3"]
+
+classifiers = [
+    "Development Status :: 4 - Beta",
+    "Intended Audience :: Education",
+    "Intended Audience :: System Administrators",
+    "License :: OSI Approved :: MIT License",
+    "Programming Language :: Python :: 3.10",
+    "Programming Language :: Python :: 3.11",
+    "Programming Language :: Python :: 3.12",
+    "Programming Language :: Python :: 3.13",
+    "Topic :: Education",
+    "Topic :: System :: Networking",
+]
+
+[project.urls]
+Homepage = "https://github.com/atharv-santosh/tracerlab"
+Repository = "https://github.com/atharv-santosh/tracerlab"
+Issues = "https://github.com/atharv-santosh/tracerlab/issues"
+
+[project.scripts]
+tracerlab = "tracerlab.cli:main"
+packet-tracer-mcp = "tracerlab.server:main"
+
+[dependency-groups]
+dev = [
+    "pytest>=8",
+    "pytest-asyncio>=0.23",
+]
+
+[build-system]
+requires = ["hatchling"]
+build-backend = "hatchling.build"
+
+[tool.hatch.build.targets.wheel]
+packages = ["src/tracerlab"]
+
+[tool.hatch.build.targets.sdist]
+include = ["src/tracerlab", "tests", "README.md", "LICENSE"]
+
+[tool.pytest.ini_options]
+testpaths = ["tests"]
+asyncio_mode = "auto"

tracerlab-0.1.5/src/tracerlab/__init__.py

@@ -0,0 +1,3 @@
+"""MCP server for Cisco Packet Tracer 9."""
+
+__version__ = "0.1.5"

tracerlab-0.1.5/src/tracerlab/bridge.py

@@ -0,0 +1,359 @@
+"""HTTP long-poll bridge to the PT script module.
+
+If another tracerlab already owns the port, jobs are relayed through it (POST /exec).
+"""
+
+from __future__ import annotations
+
+import asyncio
+import itertools
+import json
+import logging
+import os
+import time
+import urllib.error
+import urllib.request
+from dataclasses import dataclass, field
+from importlib import resources
+from typing import Any
+
+log = logging.getLogger("tracerlab.bridge")
+
+HOST = "127.0.0.1"
+PORT = int(os.environ.get("TRACERLAB_PORT") or os.environ.get("PTMCP_PORT") or "39150")
+POLL_HOLD_S = 20.0           # how long a /poll request is held open when idle
+STALE_AFTER_S = POLL_HOLD_S + 10.0
+PICKUP_S = 8.0                # a queued job must be picked up by a poll within this
+MAX_BODY = 64 * 1024 * 1024
+
+
+class PTError(RuntimeError):
+    """Raised for errors reported by Packet Tracer or the bridge."""
+
+
+class NotConnected(PTError):
+    pass
+
+
+@dataclass
+class _Job:
+    id: int
+    code: str
+    future: asyncio.Future
+    picked: asyncio.Event = field(default_factory=asyncio.Event)
+    created: float = field(default_factory=time.monotonic)
+
+
+def _bridge_js() -> str:
+    return resources.files("tracerlab").joinpath("js/bridge.js").read_text()
+
+
+def _bridge_build() -> str:
+    import hashlib
+    return hashlib.sha1(_bridge_js().encode()).hexdigest()[:10]
+
+
+def _runtime_js() -> str:
+    return resources.files("tracerlab").joinpath("js/runtime.js").read_text()
+
+
+def _runtime_version(js: str) -> str:
+    # include the hash so edits to runtime.js reload without a version bump
+    import hashlib
+    from . import __version__
+    return f"{__version__}+{hashlib.sha1(js.encode()).hexdigest()[:8]}"
+
+
+class Bridge:
+    def __init__(self, host: str = HOST, port: int = PORT) -> None:
+        self.host, self.port = host, port
+        self._queue: asyncio.Queue[_Job] = asyncio.Queue()
+        self._inflight: dict[int, _Job] = {}
+        self._ids = itertools.count(1)
+        self._chunks: dict[int, dict[int, str]] = {}
+        self._server: asyncio.base_events.Server | None = None
+        self._last_seen = 0.0
+        self._pt_info: dict[str, Any] = {}
+        self._runtime_loaded_for: str | None = None   # session token of the PT side
+        self._runtime_lock = asyncio.Lock()
+        self.mode = "stopped"                         # "owner" | "relay" | "stopped"
+
+    async def start(self) -> None:
+        # created here so they bind to the running loop
+        self._queue = asyncio.Queue()
+        self._inflight = {}
+        self._chunks: dict[int, dict[int, str]] = {}
+        self._runtime_lock = asyncio.Lock()
+        try:
+            self._server = await asyncio.start_server(self._handle, self.host, self.port)
+            self.mode = "owner"
+            log.info("bridge listening on http://%s:%d", self.host, self.port)
+        except OSError:
+            if await asyncio.to_thread(self._probe_owner):
+                self.mode = "relay"
+                log.info("port %d owned by another ptmcp; relaying", self.port)
+            else:
+                raise PTError(f"port {self.port} is in use by something that is not ptmcp "
+                              "(set PTMCP_PORT to another port and update the PT module)")
+
+    async def stop(self) -> None:
+        self._last_seen = 0.0
+        if self._server:
+            self._server.close()
+            await self._server.wait_closed()
+        for job in list(self._inflight.values()):
+            if not job.future.done():
+                job.future.set_exception(PTError("bridge stopped"))
+
+    def _probe_owner(self) -> bool:
+        try:
+            with urllib.request.urlopen(f"http://{self.host}:{self.port}/ping", timeout=2) as r:
+                return json.loads(r.read()).get("service") == "ptmcp"
+        except Exception:
+            return False
+
+    @property
+    def connected(self) -> bool:
+        return time.monotonic() - self._last_seen < STALE_AFTER_S
+
+    def status(self) -> dict[str, Any]:
+        if self.mode == "relay":
+            try:
+                with urllib.request.urlopen(f"http://{self.host}:{self.port}/ping", timeout=2) as r:
+                    d = json.loads(r.read())
+                    d["mode"] = "relay"
+                    return d
+            except Exception as e:  # pragma: no cover - network edge
+                return {"mode": "relay", "connected": False, "error": str(e)}
+        return {
+            "service": "ptmcp",
+            "mode": self.mode,
+            "connected": self.connected,
+            "seconds_since_poll": round(time.monotonic() - self._last_seen, 1) if self._last_seen else None,
+            "pt": self._pt_info,
+            "queued": self._queue.qsize(),
+            "inflight": len(self._inflight),
+        }
+
+    async def run(self, code: str, timeout: float = 60.0, *, raw: bool = False) -> Any:
+        """Run a JS function body in PT (PTM in scope) and return its JSON value."""
+        if not raw:
+            await self._ensure_runtime(timeout)
+        return await self._submit(code, timeout)
+
+    async def wait_connected(self, timeout: float) -> bool:
+        end = time.monotonic() + timeout
+        while time.monotonic() < end:
+            if self.mode == "relay" or self.connected:
+                return True
+            await asyncio.sleep(0.25)
+        return False
+
+    async def _ensure_runtime(self, timeout: float) -> None:
+        async with self._runtime_lock:
+            probe = "return (typeof PTM !== 'undefined' && PTM.VERSION) ? PTM.VERSION : null;"
+            v = await self._submit(probe, timeout)
+            js = _runtime_js()
+            want = _runtime_version(js)
+            if v != want:
+                await self._submit(js + f"\nPTM.VERSION = {json.dumps(want)};\nreturn PTM.VERSION;", timeout)
+
+    async def _submit(self, code: str, timeout: float) -> Any:
+        if self.mode == "relay":
+            return await asyncio.to_thread(self._relay, code, timeout)
+        if not self.connected:
+            raise NotConnected(
+                "Packet Tracer is not connected. Open Packet Tracer 9 with the PT-MCP script "
+                "module installed (Extensions > PT-MCP Bridge shows a green 'connected' pill). "
+                "See pt_setup_instructions.")
+        loop = asyncio.get_running_loop()
+        job = _Job(next(self._ids), code, loop.create_future())
+        self._inflight[job.id] = job
+        await self._queue.put(job)
+        try:
+            await asyncio.wait_for(job.picked.wait(), PICKUP_S)
+        except asyncio.TimeoutError:
+            self._inflight.pop(job.id, None)
+            job.future.cancel()
+            self._last_seen = 0.0
+            raise NotConnected("Packet Tracer stopped polling (PT closed, bridge window closed, or a modal "
+                               "dialog is blocking PT). Check the 'PT-MCP Bridge' window.") from None
+        try:
+            env = await asyncio.wait_for(job.future, timeout)
+        except asyncio.TimeoutError:
+            raise PTError(f"Packet Tracer did not answer within {timeout:.0f}s "
+                          "(a modal dialog open in PT blocks scripting)") from None
+        finally:
+            self._inflight.pop(job.id, None)
+        return _unwrap(env)
+
+    def _relay(self, code: str, timeout: float) -> Any:
+        req = urllib.request.Request(
+            f"http://{self.host}:{self.port}/exec",
+            data=json.dumps({"code": code, "timeout": timeout}).encode(),
+            headers={"Content-Type": "application/json"}, method="POST")
+        try:
+            with urllib.request.urlopen(req, timeout=timeout + 5) as r:
+                env = json.loads(r.read())
+        except urllib.error.HTTPError as e:
+            env = json.loads(e.read() or b"{}")
+        if env.get("bridge_error"):
+            raise (NotConnected if env.get("not_connected") else PTError)(env["bridge_error"])
+        return _unwrap(env)
+
+    async def _handle(self, reader: asyncio.StreamReader, writer: asyncio.StreamWriter) -> None:
+        try:
+            head = await reader.readuntil(b"\r\n\r\n")
+            lines = head.decode("latin-1").split("\r\n")
+            method, target, _ = lines[0].split(" ", 2)
+            headers = {k.strip().lower(): v.strip() for k, v in
+                       (l.split(":", 1) for l in lines[1:] if ":" in l)}
+            n = int(headers.get("content-length", "0") or 0)
+            if n > MAX_BODY:
+                return await self._send(writer, 413, {"error": "too large"})
+            if "chunked" in headers.get("transfer-encoding", "").lower():
+                body = await _read_chunked(reader)
+            else:
+                body = await reader.readexactly(n) if n else b""
+            path = target.split("?", 1)[0]
+            if method == "OPTIONS":
+                return await self._send(writer, 204, None)
+            if path == "/ping":
+                return await self._send(writer, 200, self.status())
+            if path == "/hello":
+                from urllib.parse import parse_qs
+                q = parse_qs(target.split("?", 1)[1]) if "?" in target else {}
+                self._pt_info["webview"] = {k: v[0] for k, v in q.items()}
+                log.info("PT web view hello: %s", self._pt_info["webview"])
+                return await self._send(writer, 200, {"ok": True})
+            if path == "/poll":
+                return await self._poll(writer, target)
+            if path == "/result" and method == "POST":
+                self._last_seen = time.monotonic()
+                self._on_result(json.loads(body))
+                return await self._send(writer, 200, {"ok": True})
+            if path == "/exec" and method == "POST":
+                return await self._exec_for_relay(writer, json.loads(body))
+            if path == "/r":           # chunked GET result from the PT web view
+                self._last_seen = time.monotonic()
+                self._on_chunk(target)
+                return await self._send_raw(writer, 200, "application/javascript", b"0;")
+            if path == "/bridge.js":
+                js = _bridge_js().replace("__PORT__", str(self.port)).replace("__BUILD__", _bridge_build())
+                return await self._send_raw(writer, 200, "application/javascript", js.encode())
+            if path == "/log":
+                log.info("PT web view: %s", target)
+                return await self._send(writer, 200, {"ok": True})
+            if path in ("/", "/bridge"):
+                return await self._send_raw(writer, 200, "text/html; charset=utf-8",
+                                            _bridge_page(self.port).encode())
+            await self._send(writer, 404, {"error": "not found"})
+        except (asyncio.IncompleteReadError, ConnectionError):
+            pass
+        except Exception as e:  # pragma: no cover - defensive
+            log.exception("http handler failed")
+            try:
+                await self._send(writer, 500, {"error": str(e)})
+            except Exception:
+                pass
+        finally:
+            try:
+                writer.close()
+            except Exception:
+                pass
+
+    async def _poll(self, writer: asyncio.StreamWriter, target: str) -> None:
+        self._last_seen = time.monotonic()
+        q: dict[str, str] = {}
+        if "?" in target:
+            from urllib.parse import parse_qs
+            q = {k: v[0] for k, v in parse_qs(target.split("?", 1)[1]).items()}
+            if q.get("pt"):
+                self._pt_info.update({"version": q.get("pt"), "session": q.get("s")})
+        try:
+            job = await asyncio.wait_for(self._queue.get(), POLL_HOLD_S)
+        except asyncio.TimeoutError:
+            self._last_seen = time.monotonic()
+            return await self._reply_poll(writer, q, {"id": 0})
+        if job.future.done():          # caller gave up while queued
+            return await self._reply_poll(writer, q, {"id": 0})
+        job.picked.set()
+        self._last_seen = time.monotonic()
+        try:
+            await self._reply_poll(writer, q, {"id": job.id, "code": job.code})
+        except ConnectionError:
+            await self._queue.put(job)  # web view vanished mid-poll; retry on next poll
+
+    async def _reply_poll(self, writer, q: dict, obj: dict) -> None:
+        cb = q.get("cb", "")
+        if cb and cb.replace("_", "").isalnum():   # JSONP for the PT web view
+            body = f"{cb}({json.dumps({**obj, 'build': _bridge_build()})});".encode()
+            return await self._send_raw(writer, 200, "application/javascript", body)
+        await self._send(writer, 200, obj)
+
+    def _on_chunk(self, target: str) -> None:
+        from urllib.parse import parse_qs
+        q = {k: v[0] for k, v in parse_qs(target.split("?", 1)[1], keep_blank_values=True).items()}
+        jid, i, n = int(q["id"]), int(q["i"]), int(q["n"])
+        parts = self._chunks.setdefault(jid, {})
+        parts[i] = q.get("d", "")
+        if len(parts) == n:
+            del self._chunks[jid]
+            self._on_result(json.loads("".join(parts[k] for k in range(n))))
+
+    def _on_result(self, msg: dict) -> None:
+        job = self._inflight.get(int(msg.get("id", 0)))
+        if job and not job.future.done():
+            job.future.set_result(msg)
+
+    async def _exec_for_relay(self, writer, req: dict) -> None:
+        try:
+            value = await self._submit(req["code"], float(req.get("timeout", 60)))
+            await self._send(writer, 200, {"ok": True, "value": value})
+        except NotConnected as e:
+            await self._send(writer, 200, {"bridge_error": str(e), "not_connected": True})
+        except PTError as e:
+            await self._send(writer, 200, {"bridge_error": str(e)})
+
+    async def _send(self, writer, status: int, obj: Any) -> None:
+        body = b"" if obj is None else json.dumps(obj).encode()
+        await self._send_raw(writer, status, "application/json", body)
+
+    async def _send_raw(self, writer, status: int, ctype: str, body: bytes) -> None:
+        reason = {200: "OK", 204: "No Content", 404: "Not Found", 413: "Too Large",
+                  500: "Error"}.get(status, "OK")
+        hdr = (f"HTTP/1.1 {status} {reason}\r\nContent-Type: {ctype}\r\n"
+               f"Content-Length: {len(body)}\r\nAccess-Control-Allow-Origin: *\r\n"
+               "Access-Control-Allow-Headers: *\r\nAccess-Control-Allow-Methods: GET, POST, OPTIONS\r\n"
+               "Cache-Control: no-store\r\nConnection: close\r\n\r\n")
+        writer.write(hdr.encode() + body)
+        await writer.drain()
+
+
+async def _read_chunked(reader: asyncio.StreamReader) -> bytes:
+    body = bytearray()
+    while True:
+        size = int((await reader.readline()).split(b";")[0].strip() or b"0", 16)
+        if size == 0:
+            await reader.readline()
+            return bytes(body)
+        if len(body) + size > MAX_BODY:
+            raise ConnectionError("body too large")
+        body += await reader.readexactly(size)
+        await reader.readline()
+
+
+def _unwrap(env: dict) -> Any:
+    """PT side replies {ok, value} or {ok:false, error, line}."""
+    if isinstance(env, str):
+        env = json.loads(env)
+    if env.get("ok"):
+        return env.get("value")
+    msg = env.get("error") or "unknown Packet Tracer error"
+    if env.get("line"):
+        msg += f" (line {env['line']})"
+    raise PTError(msg)
+
+
+def _bridge_page(port: int) -> str:
+    return resources.files("tracerlab").joinpath("js/bridge.html").read_text().replace("__PORT__", str(port))
