+# PINNStudio
+
+*A no-code desktop GUI for building, training, and visualizing Physics-Informed Neural Networks (PINNs) — built on [DeepXDE](https://github.com/lululxvi/deepxde).*
+
+---
+
+## Overview
+
+Setting up a Physics-Informed Neural Network usually means writing a new DeepXDE script for every problem: defining the PDE residual, wiring up boundary and initial conditions, picking collocation points, choosing an optimizer schedule, and writing your own plotting/error-analysis code afterward.
+
+PINNStudio replaces that boilerplate with a form. You describe the problem — the PDE, the domain, the boundary and initial conditions, the network architecture, the training schedule — through the interface, and PINNStudio generates a standalone DeepXDE/PyTorch script, runs it, and streams the training log, loss curves, and solution plots back into the GUI.
+
+It supports both **forward problems** (solve a known PDE) and **inverse problems** (estimate unknown PDE parameters from observation data), in 1D `(x, t)` and 2D `(x, y, t)`, including coupled, multi-output PDE systems.
+
+The goal is to make physics-informed machine learning accessible to researchers who need it but don't want to become deep learning engineers first. Setting up a PINN by hand touches autograd-based residuals, collocation sampling, loss weighting, and optimizer scheduling all at once — details that are easy to get subtly wrong and can cost hours of debugging before a single result can be trusted. PINNStudio lets researchers across science and engineering — materials science, mechanics, chemistry, biology, and beyond — set up and run both forward and inverse PINN problems for their own equations without building that infrastructure from scratch, on a framework that has been thoroughly tested so results are trustworthy from the first run.
+
+## Demo Video
+
+[![PINNStudio demo - setting up a PDE](https://img.youtube.com/vi/Ap-0VRwFbgE/maxresdefault.jpg)](https://youtu.be/Ap-0VRwFbgE)
+
+*Click to watch a full walkthrough of the PDE setup panel on YouTube.*
+
+## Screenshots
+
+<p align="center">
+  <img src="assets/screenshots/pde_builder.png" alt="PINNStudio — PDE, domain, and collocation point setup" width="800">
+</p>
+<p align="center"><em>Problem setup: PDE residual, domain, and collocation points.</em></p>
+
+<p align="center">
+  <img src="assets/screenshots/training_panel.png" alt="PINNStudio — network, training schedule, and adaptive training controls" width="800">
+</p>
+<p align="center"><em>Network architecture, multi-phase optimizer schedule, loss weights, and adaptive training.</em></p>
+
+<p align="center">
+  <img src="assets/results/restored_animation.gif" alt="Animated PINN solution — time evolution predicted by a restored PINNStudio model" width="500">
+</p>
+<p align="center"><em>Time evolution of a PINN solution, reconstructed from a saved checkpoint via Model Restore.</em></p>
+
+## Example Solutions
+
+<p align="center">
+  <img src="assets/results/1d_heat_solution.png" alt="PINNStudio — 1D Heat PINN solution" width="700">
+</p>
+<p align="center"><em>1D Heat: PINN-predicted solution against the bundled FEM reference data.</em></p>
+
+<p align="center">
+  <img src="assets/results/1d_allen_cahn_solution.png" alt="PINNStudio — 1D Allen-Cahn PINN solution" width="700">
+</p>
+<p align="center"><em>1D Allen-Cahn: PINN-predicted solution against the bundled FEM reference data.</em></p>
+
+<p align="center">
+  <img src="assets/results/1d_allen_cahn_inverse.png" alt="PINNStudio — 1D Allen-Cahn Inverse parameter estimation result" width="700">
+</p>
+<p align="center"><em>1D Allen-Cahn (Inverse): the unknown diffusion parameter recovered from observation data, converging to its true value during training.</em></p>
+
+## Features
+
+**Problem setup**
+- 1D `(x, t)` and 2D `(x, y, t)` problem definitions
+- Forward problems and inverse (parameter-estimation) problems
+- Free-form PDE residual editor — supports multi-output, coupled PDE systems, not just single equations
+- Boundary conditions per side, per output (Dirichlet, Neumann, Periodic), and initial conditions from an expression or a data file
+- Collocation point controls (domain / boundary / initial / test point counts, point distribution) with a 2D domain preview
+- For inverse problems, the built-in templates auto-load their end-time reference file as the observed-data source and default the observed-data loss weight to 100, so estimating a parameter needs no manual file browsing to get started (still overridable)
+
+**Training**
+- Configurable network architecture (hidden layers, neurons per layer, activation)
+- Two-stage optimization (Adam + L-BFGS) with detailed L-BFGS settings and configurable float precision
+- Multi-phase optimizer scheduling and optional IC-guided pre-training
+- Residual-based adaptive refinement (RAR)
+- Time-adaptive stepping with transfer learning between time windows
+- Mini-batch training
+- Live parameter convergence during inverse training — the estimated parameter's value prints and saves periodically throughout training, including during L-BFGS phases, not just at the end
+
+**Templates**
+- Seven built-in Quick Example templates covering common phase-field and diffusion problems (see [Built-in Templates](#built-in-templates))
+
+**Analysis & output**
+- Live training log streaming, with a Stop control
+- Error analysis against reference/ground-truth data (L2, MSE, max error; line and surface comparison plots)
+- Configurable result plotting (colormap, resolution, DPI, colorbar, snapshot count)
+- Solution data export
+- Model restore — reload a saved checkpoint to regenerate plots and re-run error analysis without retraining
+
+## Repository Structure
+
+```text
+pinnstudio/
+├── pinnstudio/
+│   ├── main.py            # Entry point
+│   ├── ui/
+│   │   └── main_window.py # PyQt6 interface — every tab, dialog, and control
+│   └── core/
+│       ├── config.py      # PINNConfig — the full problem definition
+│       ├── codegen.py     # PINNConfig -> standalone DeepXDE/PyTorch script
+│       └── runner.py      # Runs the generated script, streams output to the GUI
+├── assets/
+│   ├── screenshots/        # README screenshots
+│   └── results/             # Example output (restored_animation.gif, solution images)
+├── reference_data/          # Bundled FEM ground truth for the built-in templates
+│   ├── 1D/
+│   └── 2D/
+├── requirements.txt
+├── setup.py
+├── install.sh              # One-command setup (macOS/Linux)
+├── install.bat              # One-command setup (Windows)
+└── README.md
+```
+
+## Quick Start
+
+### Step 1: Open a terminal
+
+- **Windows:** click the Start menu, type `PowerShell`, and open **Windows PowerShell**.
+- **macOS:** press `Cmd + Space` to open Spotlight, type `Terminal`, and press Enter (or find it under Applications -> Utilities -> Terminal).
+- **Linux:** open your terminal application (commonly `Ctrl + Alt + T`, or search "Terminal" in your application menu).
+
+### Step 2: Check you have git and Python 3.9+
+
+Paste these one at a time:
+
+```bash
+git --version
+python3 --version
+```
+
+(On Windows, use `python --version` instead of `python3 --version`.)
+
+If either command isn't recognized:
+
+- **git missing?** Install it from [git-scm.com/downloads](https://git-scm.com/downloads). Default options are fine. On macOS, running `git --version` for the first time may itself prompt you to install Apple's Command Line Tools — accept and let it finish, then try again.
+- **Python missing, or older than 3.9?** Install it from [python.org/downloads](https://www.python.org/downloads/). **On Windows, check "Add python.exe to PATH"** on the installer's first screen — this is the single most common thing people miss.
+
+After installing either one, close your terminal window completely and open a new one before continuing, so the change takes effect.
+
+### Step 3: Clone and install
+
+```bash
+git clone https://github.com/AsfandyarKhan72/PINNStudio.git
+cd PINNStudio
+```
+
+**macOS / Linux:**
+```bash
+bash install.sh
+./venv/bin/pinnstudio
+```
+
+**Windows:**
+```
+install.bat
+.\venv\Scripts\pinnstudio.exe
+```
+
+The install script creates an isolated virtual environment inside the `PINNStudio` folder and installs PINNStudio and its dependencies into it — nothing is installed system-wide, and deleting the folder removes it completely. If it detects an NVIDIA GPU that the default PyTorch build can't use (an older driver, most commonly), it automatically installs a more compatible PyTorch build instead, so GPU support works out of the box on more machines. This step needs an internet connection and can take a few minutes.
+
+> **Already have a working PyTorch + CUDA setup, or no GPU at all?** You can also install with `pip install pinnstudio` - just be aware it skips the GPU compatibility check above, so if you hit a GPU-related error afterward, re-run `install.sh` / `install.bat` instead.
+
+### Step 4: Take the 60-second tour
+
+Maximize the window for the best view — PINNStudio packs a lot of controls into the left panel. With the app open, leave the dimension on **1D**, pick **1D Heat** from the *Quick Examples* dropdown, and click **Solve**. The Training Log panel will stream progress, and the loss/solution plots will populate once the run finishes.
+
+### Something not working?
+
+Open an issue on GitHub with the exact command you ran and the full error message — see [Contributing](#contributing).
+
+## Running PINNStudio Again
+
+You only need to run the install steps above once. After that, launch PINNStudio again anytime with:
+
+**macOS / Linux**, from inside the `PINNStudio` folder:
+```bash
+./venv/bin/pinnstudio
+```
+
+**Windows**, from inside the `PINNStudio` folder:
+```
+.\venv\Scripts\pinnstudio.exe
+```
+
+That's it - no need to reinstall or recreate the virtual environment.
+
+## What Gets Installed
+
+`install.sh` / `install.bat` (used in Quick Start above) set up an isolated Python virtual environment and install:
+
+- [DeepXDE](https://github.com/lululxvi/deepxde) (PyTorch backend)
+- PyTorch
+- PyQt6
+- NumPy
+- Matplotlib
+- Pandas
+
+A CUDA-capable GPU is optional but recommended for larger 2D problems and inverse runs.
+
+## Built-in Templates
+
+Each template preconfigures the PDE, domain, boundary/initial conditions, network size, and training schedule — pick one from *Quick Examples*, then adjust as needed.
+
+All seven templates ship with bundled FEM reference data (see [`reference_data/`](reference_data)), generated independently of the PINN, so Error Analysis auto-configures against real ground truth the moment you load them — no setup, no external download.
+
+| Template | Dimension | System | Reference data |
+|---|---|---|---|
+| 1D Heat | 1D | Single PDE | ✅ bundled |
+| 1D Allen-Cahn | 1D | Single PDE | ✅ bundled |
+| 1D Cahn-Hilliard | 1D | Coupled (2 outputs) | ✅ bundled |
+| 2D Heat (Dirichlet/Neumann) | 2D | Single PDE | ✅ bundled |
+| 2D Allen-Cahn (Mattey) | 2D | Single PDE | ✅ bundled |
+| 2D Allen-Cahn (Wight) | 2D | Single PDE | ✅ bundled |
+| 2D Cahn-Hilliard (Wight) | 2D | Coupled (2 outputs) | ✅ bundled |
+
+### 1D Heat
+
+$$\frac{\partial u}{\partial t} = 0.4\frac{\partial^2 u}{\partial x^2}, \qquad x \in [0, 1],\ t \in [0, 1]$$
+
+Initial condition: $u(x, 0) = \sin(\pi x)$. Dirichlet boundaries.
+
+### 1D Allen-Cahn
+
+$$\frac{\partial u}{\partial t} = 0.0001\frac{\partial^2 u}{\partial x^2} - 5u^3 + 5u, \qquad x \in [-1, 1],\ t \in [0, 1]$$
+
+Initial condition: $u(x, 0) = x^2\cos(\pi x)$. Periodic boundaries.
+
+### 1D Cahn-Hilliard
+
+Fourth-order phase separation, split into two coupled second-order equations:
+
+$$\frac{\partial u}{\partial t} = \frac{\partial^2 v}{\partial x^2}, \qquad v = 0.01(u^3 - u) - 10^{-6}\frac{\partial^2 u}{\partial x^2}, \qquad x \in [-1, 1],\ t \in [0, 1]$$
+
+Initial condition: $u(x, 0) = -\cos(2\pi x)$. Periodic boundaries.
+
+### 2D Heat (Dirichlet/Neumann)
+
+$$\frac{\partial u}{\partial t} = 0.4\left(\frac{\partial^2 u}{\partial x^2} + \frac{\partial^2 u}{\partial y^2}\right), \qquad (x, y) \in [0, 1]^2,\ t \in [0, 1]$$
+
+Initial condition: $u(x, y, 0) = 0$. Mixed Dirichlet/Neumann boundaries.
+
+### 2D Allen-Cahn (Mattey)
+
+Benchmark problem after Mattey & Ghosh (2022) — see [References](#references).
+
+$$\frac{\partial u}{\partial t} = 0.0001\left(\frac{\partial^2 u}{\partial x^2} + \frac{\partial^2 u}{\partial y^2}\right) - 5(u^3 - u), \qquad (x, y) \in [0, 1]^2,\ t \in [0, 1]$$
+
+Initial condition: $u(x, y, 0) = \sin(4\pi x)\cos(4\pi y)$. Periodic boundaries.
+
+### 2D Allen-Cahn (Wight)
+
+Benchmark problem after Wight & Zhao (2021) — see [References](#references).
+
+$$\frac{\partial u}{\partial t} = 0.00625\left(\frac{\partial^2 u}{\partial x^2} + \frac{\partial^2 u}{\partial y^2}\right) - 10(u^3 - u), \qquad (x, y) \in [0, 1]^2,\ t \in [0, 10]$$
+
+Initial condition: a smooth circular interface, $u(x, y, 0) = \tanh\left(\dfrac{0.35 - \sqrt{(x-0.5)^2 + (y-0.5)^2}}{0.05}\right)$. Periodic boundaries.
+
+### 2D Cahn-Hilliard (Wight)
+
+Benchmark problem after Wight & Zhao (2021) — see [References](#references). Two-phase separation, split into a composition field $u$ and a chemical potential $\mu$:
+
+$$\frac{\partial u}{\partial t} = \frac{\partial^2 \mu}{\partial x^2} + \frac{\partial^2 \mu}{\partial y^2}, \qquad \mu = (u^3 - u) - 0.1\left(\frac{\partial^2 u}{\partial x^2} + \frac{\partial^2 u}{\partial y^2}\right), \qquad (x, y) \in [-0.5, 0.5]^2$$
+
+Initial condition: two circular domains of opposite phase. Periodic boundaries.
+
+## How It Works
+
+PINNStudio doesn't wrap DeepXDE at runtime — it **generates code**. Every setting in the GUI maps to a field on a `PINNConfig` dataclass ([`pinnstudio/core/config.py`](pinnstudio/core/config.py)); clicking **Solve** passes that config to [`codegen.py`](pinnstudio/core/codegen.py), which writes out a complete, standalone DeepXDE/PyTorch script, and [`runner.py`](pinnstudio/core/runner.py) executes it as a subprocess, streaming stdout back into the Training Log panel in real time.
+
+Because the output of every run is an ordinary Python script, you can take it and run it outside the GUI, hand it to a cluster job, or use it as a starting point for a hand-written DeepXDE project.
+
+## Citation
+
+If PINNStudio is useful in your work, please cite it — see [`CITATION.cff`](CITATION.cff):
+
+```bibtex
+@software{khan2026pinnstudio,
+  author  = {Khan, Asfandyar},
+  title   = {PINNStudio: A No-Code GUI for Physics-Informed Neural Networks},
+  year    = {2026},
+  url     = {https://github.com/AsfandyarKhan72/PINNStudio}
+}
+```
+
+## References
+
+- Lu, L., Meng, X., Mao, Z., & Karniadakis, G. E. (2021). DeepXDE: A deep learning library for solving differential equations. *SIAM Review*, 63(1), 208–228. https://doi.org/10.1137/19M1274067
+- Mattey, R., & Ghosh, S. (2022). A novel sequential method to train physics informed neural networks for Allen-Cahn and Cahn-Hilliard equations. *Computer Methods in Applied Mechanics and Engineering*, 390, 114474. https://doi.org/10.1016/j.cma.2021.114474
+- Wight, C. L., & Zhao, J. (2021). Solving Allen-Cahn and Cahn-Hilliard equations using the adaptive physics informed neural networks. *Communications in Computational Physics*, 29(3), 930–954. https://doi.org/10.4208/cicp.OA-2020-0086
+
+## Acknowledgment
+
+PINNStudio is built on [DeepXDE](https://github.com/lululxvi/deepxde) (Lu et al., 2021) and PyQt6. The 2D Allen-Cahn and Cahn-Hilliard Quick Example templates follow the problem setups described in Mattey & Ghosh (2022) and Wight & Zhao (2021) — see [References](#references).
+
+Developed under the supervision of Prof. Mahmood Mamivand, Computational Materials Design Lab, Boise State University.
+
+The authors appreciate the support of the National Science Foundation grant DMR-2142935. We would like to acknowledge the high-performance computing support of the Borah compute cluster (DOI: 10.18122/oit/3/boisestate) provided by Boise State University's Research Computing Department.
+
+## Contributing
+
+Bug reports, feature requests, and pull requests are welcome — see [`CONTRIBUTING.md`](CONTRIBUTING.md).
+
+## Contact
+
+Asfandyar Khan
+PhD Candidate, Materials Science and Engineering
+Boise State University
+Email: [asfandyarkhan@u.boisestate.edu](mailto:asfandyarkhan@u.boisestate.edu)
+
+## License
+
+Released under the MIT License. See [`LICENSE`](LICENSE) for details.
