lenkraster 0.1.0__tar.gz

lenkraster-0.1.0/ASSET_LICENSE.md

@@ -0,0 +1,34 @@
+# Asset license
+
+Copyright (c) 2026 Ryan Lenk.
+
+Unless a file states otherwise, every repository-authored visual asset, palette JSON,
+example fixture, and documentation image in this repository is licensed under the
+MIT License in [`LICENSE`](LICENSE), to the extent the material is protected by copyright.
+This permission includes the four built-in palettes:
+
+- Lenk Cinder 16
+- Lenk Fern 4
+- Lenk Signal 16
+- Lenk Studio 32
+
+Those palettes were created specifically for LenkRaster from independently selected RGB
+values. They are not derived from or compatible-name copies of a third-party palette.
+Their `author` field identifies Ryan Lenk. The exact release-candidate files are pinned
+here so later changes are visible:
+
+| File | SHA-256 |
+|---|---|
+| `lenk-cinder-16.json` | `ce0fbb4c6e96b814356da83e23bb1fac536026a5bab198449008d1e37bf666d1` |
+| `lenk-fern-4.json` | `9e3a08c13a530ce442085c6d724e57cd61f198db9bb456124fe2e25973a60683` |
+| `lenk-signal-16.json` | `07eb4c2220e3cf72be559907ffc1dcc6d92401bf44b8716fe350e610018bd8fb` |
+| `lenk-studio-32.json` | `d5570602f593d4d2645d142c81b06cb38892b85eb5873b36bde95915fc68f51a` |
+
+The demonstration artwork was created at Ryan Lenk's direction with OpenAI image-generation
+tools and without an external character, logo, or artwork reference. The license grant
+above applies to any rights Ryan Lenk can license in those outputs. It does not claim
+exclusive rights in unprotectable, public-domain, or third-party material.
+
+The embedded content-credentials metadata in generated images is provenance information,
+not an additional license or endorsement. Aseprite was used only as an operator-installed
+editing/export tool and is not bundled with these assets.

lenkraster-0.1.0/CHANGELOG.md

@@ -0,0 +1,43 @@
+# Changelog
+
+All notable changes to LenkRaster will be documented here.
+
+The format follows [Keep a Changelog](https://keepachangelog.com/en/1.1.0/), and releases
+use semantic versioning once the first public tag is created.
+
+## [Unreleased]
+
+### Added
+
+- Optional, bounded Aseprite CLI export and direct cycle-QA integration.
+- Two Aseprite MCP tools and matching CLI/Python APIs.
+- Public security policy, contributing guide, release checklist, dependency audit, and
+  secret/path artifact checks.
+
+### Changed
+
+- Adopt the pre-release `LenkRaster` identity across the distribution, import package,
+  command-line entry points, local MCP server, repository links, and environment variables.
+- Replace all previously bundled palettes with four original Ryan Lenk palettes and add
+  explicit asset licensing, provenance, third-party notices, and a name-screen record.
+
+### Security
+
+- Require an explicit MCP trusted root for every tool call.
+- Require Python 3.10+, Pillow 12.3+, and a current reproducible CI dependency set.
+- Validate Aseprite metadata and PNG sheets before publishing or analysis.
+- Keep Aseprite invocation fixed, non-shell, time-bounded, and create-only.
+- Contain user-owned palette files below an explicit trusted root and validate their
+  schema, encoded size, metadata, color count, and unique RGB values before image work.
+
+### Removed
+
+- Private project-specific calibration reports, adapter code, tests, and handoff material
+  from the public source tree.
+- All externally authored palette data and ambiguous palette provenance; users may supply
+  lawfully obtained values through the bounded custom-palette interface.
+
+## [0.1.0] - Unreleased
+
+- Initial bounded critic, palette lab, animation QA, golden-corpus runner, CLI, and local
+  stdio MCP server.

lenkraster-0.1.0/CONTRIBUTING.md

@@ -0,0 +1,44 @@
+# Contributing
+
+LenkRaster welcomes small, evidence-backed improvements to its deterministic pixel-art
+engines and trusted-local interfaces.
+
+## Development setup
+
+Use Python 3.10 or newer in an isolated environment:
+
+```console
+python -m venv .venv
+python -m pip install --upgrade pip
+python -m pip install -c requirements/ci.txt -e ".[dev]"
+python -m pytest tests -q
+```
+
+Before submitting a change, also run:
+
+```console
+python -m pip check
+python -m pip_audit --skip-editable
+python -m bandit -q -r src
+python scripts/audit_public_tree.py
+python -m build
+python scripts/audit_public_tree.py dist
+```
+
+## Engineering expectations
+
+- Reproduce defects with a failing test before changing implementation.
+- Keep all file, image, animation, JSON, request, and subprocess work explicitly bounded.
+- Preserve trusted-root containment, path-free public failures, and create-only outputs.
+- Use argument vectors with `shell=False`; never accept arbitrary subprocess flags or
+  scripts through MCP.
+- Keep the MCP server local stdio only.
+- Preserve advisory semantics. A score or cycle result is not art approval.
+- Add synthetic fixtures in tests. Never commit private, client-owned, or proprietary art.
+- Do not vendor or redistribute Aseprite, its binaries, or licensed sample content.
+- Do not add secrets, workstation paths, personal email addresses, or `.env` files.
+
+## Pull requests
+
+Describe the original scenario, the new test, security-boundary impact, and the exact
+verification performed. Keep unrelated refactors separate.

lenkraster-0.1.0/LICENSE

@@ -0,0 +1,20 @@
+MIT License
+
+Copyright (c) 2026 Ryan Lenk
+
+Permission is hereby granted, free of charge, to any person obtaining a copy
+of this software and associated documentation files (the "Software"), to deal
+in the Software without restriction, including without limitation the rights
+to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+copies of the Software, and to permit persons to whom the Software is
+furnished to do so, subject to the following conditions:
+
+The above copyright notice and this permission notice shall be included in all
+copies or substantial portions of the Software.
+
+THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
+AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+LIABILITY, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE
+OR OTHER DEALINGS IN THE SOFTWARE.

lenkraster-0.1.0/MANIFEST.in

@@ -0,0 +1,19 @@
+include CHANGELOG.md
+include ASSET_LICENSE.md
+include CONTRIBUTING.md
+include LICENSE
+include README.md
+include PYPI_README.md
+include SECURITY.md
+include THIRD_PARTY_NOTICES.md
+recursive-include docs *.md
+recursive-include mcp *.py
+recursive-include requirements *.in *.txt
+recursive-include scripts *.py
+recursive-include skills *.md
+recursive-include tests *.py
+global-exclude *.py[cod]
+global-exclude .DS_Store
+prune .claude
+prune build
+prune dist

lenkraster-0.1.0/PKG-INFO

@@ -0,0 +1,412 @@
+Metadata-Version: 2.4
+Name: lenkraster
+Version: 0.1.0
+Summary: Bounded pixel-art critique, palette, animation QA, Aseprite, and local MCP tools.
+Author: Ryan Lenk
+License-Expression: MIT
+Project-URL: Homepage, https://github.com/itsryanlenk/lenkraster
+Project-URL: Documentation, https://github.com/itsryanlenk/lenkraster#readme
+Project-URL: Issues, https://github.com/itsryanlenk/lenkraster/issues
+Project-URL: Security, https://github.com/itsryanlenk/lenkraster/security/policy
+Keywords: pixel-art,sprites,aseprite,game-dev,mcp,color,critique
+Classifier: Development Status :: 4 - Beta
+Classifier: Intended Audience :: Developers
+Classifier: Programming Language :: Python :: 3
+Classifier: Programming Language :: Python :: 3.10
+Classifier: Programming Language :: Python :: 3.11
+Classifier: Programming Language :: Python :: 3.12
+Classifier: Programming Language :: Python :: 3.13
+Classifier: Programming Language :: Python :: 3.14
+Classifier: Topic :: Artistic Software
+Classifier: Topic :: Games/Entertainment
+Requires-Python: >=3.10
+Description-Content-Type: text/markdown
+License-File: LICENSE
+License-File: ASSET_LICENSE.md
+License-File: THIRD_PARTY_NOTICES.md
+Requires-Dist: numpy<3,>=2.0
+Requires-Dist: Pillow<13,>=12.3
+Provides-Extra: mcp
+Provides-Extra: dev
+Requires-Dist: bandit==1.9.4; extra == "dev"
+Requires-Dist: build==1.5.0; extra == "dev"
+Requires-Dist: pip-audit==2.10.1; extra == "dev"
+Requires-Dist: pytest==9.1.1; extra == "dev"
+Requires-Dist: setuptools==84.0.0; extra == "dev"
+Dynamic: license-file
+
+# LenkRaster
+
+![LenkRaster — bounded pixel-art tools](https://raw.githubusercontent.com/itsryanlenk/lenkraster/main/docs/assets/lenkraster-readme-banner.png)
+
+LenkRaster is a deterministic, bounded toolkit for inspecting and preparing pixel art.
+It combines craft critique, palette operations, animation-cycle QA, an optional Aseprite
+CLI bridge, a command-line interface, a Python API, and a trusted-local stdio MCP server.
+
+LenkRaster is designed for agent workflows without turning an agent into an art director:
+its reports are advisory evidence and retry hints. It does not approve artwork, replace
+human review, or replace a project's composition, provenance, and release gates.
+
+## What it does
+
+- Scores bounded PNG sprites against explainable pixel-craft checks.
+- Builds OKLCH hue-shifted material ramps.
+- Quantizes PNGs against original built-ins or bounded user-owned palette JSON without
+  overwriting existing files.
+- Reports same-hue contrast and palette structure.
+- Measures animation motion and visibility using rendered-pixel math.
+- Exports and directly checks trusted local `.ase`/`.aseprite` documents through a
+  separately installed Aseprite CLI.
+- Exposes the same bounded operations to local MCP clients over stdio.
+- Replays user-owned, SHA-256-pinned golden corpora without promoting results to approval.
+
+No GPU, API key, model download, browser, network service, or persistent daemon is
+required.
+
+## See it in action
+
+These are real outputs from the current LenkRaster CLI. The public source art and its
+provenance are documented in
+[docs/examples](https://github.com/itsryanlenk/lenkraster/blob/main/docs/examples/README.md).
+
+### One fixed palette across an animation
+
+Palette normalization is constraint enforcement for asset pipelines, not an attempt to
+"improve" an artist's source image. This four-frame hammer cycle intentionally contains
+frame-exclusive RGB variation. LenkRaster maps it to one repository-owned 48-color target
+without changing the poses or overwriting the source.
+
+| Source cycle | Fixed target | Verified output |
+|---|---|---|
+| 77,766 distinct visible RGB values | 48 user-owned colors | 48/48 used; every visible output color belongs to the target |
+
+![Four-frame blacksmith automaton hammer cycle mapped to one fixed 48-color palette](https://raw.githubusercontent.com/itsryanlenk/lenkraster/main/docs/examples/hammer-cycle-fixed-palette.png)
+
+<details>
+<summary>Inspect the unnormalized source strip</summary>
+
+![The same four-frame hammer cycle before fixed-palette normalization](https://raw.githubusercontent.com/itsryanlenk/lenkraster/main/docs/examples/hammer-cycle-source.png)
+
+</details>
+
+```console
+lenkraster quantize docs/examples/hammer-cycle-source.png \
+  --palette-file docs/examples/hammer-cycle-palette.json \
+  --root <absolute-path-to-repository> \
+  --out hammer-cycle-local-output.png
+```
+
+Use the same palette file and settings for separately stored frames. `cycle` measures
+rendered-pixel motion and visibility; it does not claim to judge visual quality or prove
+palette membership.
+
+### Aseprite export and cycle QA
+
+The same four poses were assembled into a tagged `hammer` animation and exercised through
+the separately installed, SHA-256-pinned Aseprite CLI bridge:
+
+| Validated export | Advisory cycle report |
+|---|---|
+| 4 frames; 543x724 each; 120 ms per frame | `PASS`; 3/3 adjacent transitions detected; no issues |
+
+LenkRaster exported the horizontal sheet and sanitized metadata into a new directory, then
+ran the cycle check from a separate transient export. The `.aseprite` working document is
+not distributed in the package or public repository.
+
+### Color construction
+
+| Seven-stop OKLCH material ramp | Ordered 4x4 Bayer dither |
+|---|---|
+| ![Seven-stop orange material ramp with hue-shifted shadows and highlights](https://raw.githubusercontent.com/itsryanlenk/lenkraster/main/docs/examples/material-ramp.png) | ![Ordered blue and yellow Bayer dither](https://raw.githubusercontent.com/itsryanlenk/lenkraster/main/docs/examples/ordered-dither.png) |
+
+```console
+lenkraster ramp --color "#FF6B35" --stops 7 --drift -10 \
+  --out docs/examples/material-ramp.png
+lenkraster dither --a "#2196F3" --b "#FFEB3B" --size 256 --order 4 \
+  --out docs/examples/ordered-dither.png
+```
+
+These examples demonstrate deterministic transformations, not artwork approval; critique
+and animation QA remain advisory evidence for human review.
+
+## Security model
+
+LenkRaster processes image files, so limits and containment are part of its public
+contract:
+
+- MCP file operations require an explicit, existing `LENKRASTER_TRUSTED_ROOT`.
+- Resolved inputs and outputs must remain beneath that root; traversal and symlink escapes
+  fail closed.
+- PNG encoded bytes, decoded pixels, dimensions, frame discovery, frame count, total
+  pixels, pair work, JSON size, and MCP request size are bounded.
+- Quantized and Aseprite exports are create-only. Existing files and directories are never
+  overwritten.
+- Public errors are fixed messages and do not include local paths or subprocess output.
+- The server is trusted-local stdio only. It is not a network service and must not be
+  exposed as public HTTP.
+
+The optional Aseprite bridge executes a native application and is not an operating-system
+sandbox. Only process documents you trust. Use an OS sandbox for hostile or untrusted
+Aseprite files.
+
+See [SECURITY.md](https://github.com/itsryanlenk/lenkraster/blob/main/SECURITY.md) for
+reporting and the maintained threat boundary.
+
+## Requirements
+
+- Python 3.10 or newer
+- NumPy 2.x
+- Pillow 12.3 or newer within the 12.x line
+- Optional: Aseprite 1.3.17.2 or newer in the 1.3 line for `.ase`/`.aseprite`
+  integration
+
+Aseprite is not bundled, downloaded, or redistributed by LenkRaster. It is a separate
+product with its own license. LenkRaster is compatible with its documented CLI and is not
+affiliated with or endorsed by Aseprite.
+
+## Install
+
+From PyPI:
+
+```console
+python -m pip install lenkraster
+```
+
+The distribution and installed Python package are both `lenkraster`. The command-line
+entry points are `lenkraster` and `lenkraster-mcp`.
+
+From a checked-out source tree:
+
+```console
+python -m venv .venv
+.venv/Scripts/python -m pip install --upgrade pip
+.venv/Scripts/python -m pip install .
+```
+
+On macOS or Linux, use `.venv/bin/python` in place of
+`.venv/Scripts/python`.
+
+For development:
+
+```console
+python -m pip install -c requirements/ci.txt -e ".[dev]"
+python -m pytest tests -q
+python -m pip check
+python -m pip_audit --skip-editable
+```
+
+## CLI
+
+```console
+lenkraster critique sprite.png
+lenkraster critique sheet.png --json report.json
+lenkraster ramp --color "#d77643" --stops 5 --drift -8 --out swatches.png
+lenkraster dither --a "#ac530b" --b "#ffe0cc" --order 4 --out gradient.png
+lenkraster check --file sprite.png
+lenkraster quantize frame.png --palette lenk-studio-32 --out snapped.png
+lenkraster quantize frame.png --palette-file palettes/my-palette.json \
+  --root <absolute-path-to-sprite-workspace> --out snapped-custom.png
+lenkraster palettes
+lenkraster cycle "frame-*.png"
+lenkraster shadow corpus/manifest.json --manifest-sha256 <sha256>
+```
+
+`cycle` returns exit code 0 for `PASS` and 1 for `REVIEW`. A review result is
+not a release rejection unless your project has separately adopted that policy.
+
+### User-owned palette files
+
+`lenkraster palettes` lists the four original built-ins: `lenk-cinder-16`, `lenk-fern-4`,
+`lenk-signal-16`, and `lenk-studio-32`. A user-owned palette is a UTF-8 JSON file below an
+explicit trusted root:
+
+| Built-in | Colors | Intended use |
+|---|---:|---|
+| `lenk-fern-4` | 4 | Compact moss-and-ink monochrome work |
+| `lenk-cinder-16` | 16 | Warm industrial sprites and environment tiles |
+| `lenk-signal-16` | 16 | High-contrast characters and UI accents |
+| `lenk-studio-32` | 32 | General-purpose multi-material sprite work |
+
+```json
+{
+  "name": "My fixed palette",
+  "author": "Local user",
+  "colors": ["102030", "f0e0d0"]
+}
+```
+
+Palette files are limited to 16 KiB, 2-64 unique six-digit RGB colors, exact keys, and
+bounded path-free metadata. MCP callers use `palette_file` relative to
+`LENKRASTER_TRUSTED_ROOT`; CLI callers use `--palette-file` with `--root`.
+
+Common 4-, 16-, and 32-color external palette workflows were exercised during
+pre-publication compatibility testing. Users may place any lawfully obtained palette in
+their own local JSON file and use the same `palette_file` interface. Users remain
+responsible for the provenance and permitted use of supplied palettes.
+
+### Optional Aseprite bridge
+
+Set the executable to an absolute path:
+
+```console
+LENKRASTER_ASEPRITE_EXECUTABLE=<absolute-path-to-aseprite>
+LENKRASTER_ASEPRITE_SHA256=<sha256-of-that-executable>
+```
+
+The SHA-256 pin is strongly recommended. LenkRaster checks it before the version probe
+and again immediately before export, and rejects unsupported Aseprite versions. Recompute
+the pin whenever Aseprite is intentionally updated.
+
+Export a horizontal sheet and sanitized manifest into a directory that does not yet exist:
+
+```console
+lenkraster aseprite-export hero.aseprite \
+  --root <absolute-path-to-sprite-workspace> \
+  --out-dir exports/hero \
+  --tag walk
+```
+
+Run cycle QA without retaining exported files:
+
+```console
+lenkraster aseprite-cycle hero.aseprite \
+  --root <absolute-path-to-sprite-workspace> \
+  --tag walk \
+  --motion-threshold 12 \
+  --min-motion-pixels 6
+```
+
+The bridge passes a fixed argument vector to Aseprite batch mode. Callers cannot supply
+scripts, arbitrary flags, output filenames, or shell fragments. Tag and layer selections
+are optional bounded labels; nested layers use `/` (for example,
+`characters/hero body`) and Unicode names are supported. Each invocation uses a fresh
+disposable Aseprite user/configuration folder and a snapshotted input document, so the
+operator's normal Aseprite extensions and preferences are not loaded. Validated output is
+written to a hidden staging directory and becomes visible with one final create-only
+directory rename.
+
+## MCP server
+
+Any MCP-speaking client can launch the installed one-shot stdio server. Always use
+absolute paths in the client configuration:
+
+```json
+{
+  "mcpServers": {
+    "lenkraster": {
+      "command": "<absolute-path-to-venv>/Scripts/lenkraster-mcp.exe",
+      "args": [],
+      "env": {
+        "LENKRASTER_TRUSTED_ROOT": "<absolute-path-to-disposable-sprite-workspace>",
+        "LENKRASTER_ASEPRITE_EXECUTABLE": "<absolute-path-to-aseprite>",
+        "LENKRASTER_ASEPRITE_SHA256": "<sha256-of-that-executable>"
+      }
+    }
+  }
+}
+```
+
+The Aseprite variables are optional when those tools are not used. The trusted-root
+variable is required for every tool call. MCP clients cannot override the configured
+executable or its SHA-256 pin.
+
+LenkRaster exposes seven tools:
+
+| Tool | Purpose |
+|---|---|
+| `critique_sprite` | Score one bounded PNG and return findings/retry hints. |
+| `make_ramp` | Generate a bounded OKLCH material ramp. |
+| `palette_quantize` | Create a new PNG using an original built-in or trusted user palette. |
+| `contrast_report` | Report same-hue lightness separation. |
+| `qa_cycle` | Check 2-32 same-size PNG frames matched by a relative glob. |
+| `aseprite_export` | Create a validated sheet and path-free manifest. |
+| `qa_aseprite_cycle` | Export transiently and run bounded cycle QA. |
+
+Project-specific adapters and private art corpora are intentionally outside the MCP
+surface and the distribution.
+
+## Python API
+
+```python
+from lenkraster import (
+    critique,
+    export_aseprite_document,
+    load_palette_file,
+    make_ramp,
+    qa_aseprite_document,
+    qa_cycle,
+    quantize_file,
+)
+
+report = critique("sprite.png")
+print(report["score"], report["retry_hints"])
+
+ramp = make_ramp("#d77643", stops=5, drift=-8.0)
+quantize_file("frame.png", "lenk-studio-32", "snapped.png")
+load_palette_file("palettes/my-palette.json", trusted_root="sprite-workspace")
+quantize_file(
+    "frame.png",
+    None,
+    "snapped-custom.png",
+    palette_file="palettes/my-palette.json",
+    palette_root="sprite-workspace",
+)
+
+motion = qa_cycle(
+    ["base.png", "frame-1.png", "frame-2.png"],
+    roi=(12, 8, 44, 40),
+    transition_groups={"walk": [(0, 1), (1, 2)]},
+)
+
+export_manifest = export_aseprite_document(
+    "hero.aseprite",
+    "exports/hero",
+    trusted_root="sprite-workspace",
+)
+
+aseprite_motion = qa_aseprite_document(
+    "hero.aseprite",
+    trusted_root="sprite-workspace",
+    tag="walk",
+)
+```
+
+For the Aseprite Python API, configure `LENKRASTER_ASEPRITE_EXECUTABLE` or pass an
+absolute executable path through the trusted local API. MCP clients cannot choose the
+executable.
+
+## Design laws
+
+- **Rendered-pixel law:** RGB beneath fully transparent pixels does not affect critique,
+  contrast, quantization, or motion.
+- **Shared-palette law:** animation frames should use the same fixed target palette and
+  settings.
+- **Motion-group law:** every authored gesture group must independently contain a
+  qualifying transition.
+- **Vision-is-not-QA law:** animation correctness is computed from pixels, not inferred
+  from thumbnails.
+- **Bounded-work law:** encoded bytes, decoded pixels, frames, discovery, and comparisons
+  fail closed at explicit ceilings.
+- **Advisory law:** LenkRaster produces evidence and retry hints, never art approval.
+
+## Golden-corpus regression
+
+`lenkraster shadow` accepts a bounded, caller-hash-pinned manifest containing
+user-owned PNG fixtures. Automated cases report `BASELINE_MATCH` or `DRIFT`;
+contextual cases remain `HUMAN_REVIEW`. Do not commit proprietary or private artwork to
+this public repository.
+
+## Development and release
+
+Contributions are welcome; read
+[CONTRIBUTING.md](https://github.com/itsryanlenk/lenkraster/blob/main/CONTRIBUTING.md).
+Public artifact checks
+and release provenance steps are documented in
+[docs/release-checklist.md](https://github.com/itsryanlenk/lenkraster/blob/main/docs/release-checklist.md).
+
+The source and repository-authored assets are MIT licensed. See
+[ASSET_LICENSE.md](https://github.com/itsryanlenk/lenkraster/blob/main/ASSET_LICENSE.md)
+for palette and image scope, and
+[THIRD_PARTY_NOTICES.md](https://github.com/itsryanlenk/lenkraster/blob/main/THIRD_PARTY_NOTICES.md)
+for dependency, method, and optional-tool notices. User-supplied palettes and Aseprite
+itself are not part of this distribution.
