dysonsphere 0.4.0__tar.gz

dysonsphere-0.4.0/.github/workflows/pages.yml

@@ -0,0 +1,28 @@
+name: Deploy to GitHub Pages
+
+on:
+  push:
+    branches:
+      - main
+
+jobs:
+  deploy:
+    runs-on: ubuntu-latest
+    environment:
+      name: github-pages
+      url: ${{ steps.deploy.outputs.page_url }}
+    permissions:
+      pages: write
+      id-token: write
+
+    steps:
+      - uses: actions/checkout@v4
+
+      - name: Upload pages artifact
+        uses: actions/upload-pages-artifact@v3
+        with:
+          path: docs/
+
+      - name: Deploy to GitHub Pages
+        id: deploy
+        uses: actions/deploy-pages@v4

dysonsphere-0.4.0/.github/workflows/publish.yml

@@ -0,0 +1,25 @@
+name: Publish to PyPI
+
+on:
+  push:
+    tags:
+      - "v*"
+
+jobs:
+  publish:
+    runs-on: ubuntu-latest
+    environment: pypi
+    permissions:
+      id-token: write
+
+    steps:
+      - uses: actions/checkout@v4
+
+      - name: Install uv
+        uses: astral-sh/setup-uv@v5
+
+      - name: Build
+        run: uv build
+
+      - name: Publish
+        run: uv publish

dysonsphere-0.4.0/.gitignore

@@ -0,0 +1,57 @@
+# Compiled source #
+###################
+*.com
+*.class
+*.dll
+*.exe
+*.o
+*.so
+
+# Logs and databases #
+######################
+*.log
+*.sql
+*.sqlite
+
+# Cache files #
+###############
+__pycache__
+*.pyc
+
+# OS generated files #
+######################
+.DS_Store
+.DS_Store?
+._*
+.Spotlight-V100
+.Trashes
+ehthumbs.db
+Thumbs.db
+
+# Notes / scratchpads #
+#########
+*rule*.md
+*thoughts.md
+*notes.md
+*planning.md
+*plans.md
+*scratch*
+
+# Virtual environments #
+########################
+.venv
+*venv
+pipenv
+*conda*
+
+# Raw data files #
+##################
+*.tif
+*.tiff
+*.nd2
+
+# Project-specific #
+*.svg
+*.json
+!docs/thumbnail_light.png

dysonsphere-0.4.0/.python-version

@@ -0,0 +1 @@
+3.11

dysonsphere-0.4.0/LICENSE

@@ -0,0 +1,21 @@
+MIT License
+
+Copyright (c) 2026 dkkung
+
+Permission is hereby granted, free of charge, to any person obtaining a copy
+of this software and associated documentation files (the "Software"), to deal
+in the Software without restriction, including without limitation the rights
+to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+copies of the Software, and to permit persons to whom the Software is
+furnished to do so, subject to the following conditions:
+
+The above copyright notice and this permission notice shall be included in all
+copies or substantial portions of the Software.
+
+THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
+AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
+SOFTWARE.

dysonsphere-0.4.0/PKG-INFO

@@ -0,0 +1,436 @@
+Metadata-Version: 2.4
+Name: dysonsphere
+Version: 0.4.0
+Summary: An Altair configuration wrapper with perceptually uniform palettes and chart utilities for publication-ready figures.
+Project-URL: Repository, https://github.com/dkkung/dysonsphere
+Author-email: dkkung <128324842+dkkung@users.noreply.github.com>
+License: MIT License
+
+        Copyright (c) 2026 dkkung
+
+        Permission is hereby granted, free of charge, to any person obtaining a copy
+        of this software and associated documentation files (the "Software"), to deal
+        in the Software without restriction, including without limitation the rights
+        to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+        copies of the Software, and to permit persons to whom the Software is
+        furnished to do so, subject to the following conditions:
+
+        The above copyright notice and this permission notice shall be included in all
+        copies or substantial portions of the Software.
+
+        THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+        IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+        FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
+        AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+        LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+        OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
+        SOFTWARE.
+License-File: LICENSE
+Keywords: altair,color,oklab,palette,theme,vega-lite,visualization
+Classifier: Development Status :: 4 - Beta
+Classifier: Intended Audience :: Science/Research
+Classifier: License :: OSI Approved :: MIT License
+Classifier: Operating System :: OS Independent
+Classifier: Programming Language :: Python :: 3
+Classifier: Topic :: Scientific/Engineering :: Visualization
+Requires-Python: >=3.11
+Requires-Dist: altair>=5.5.0
+Requires-Dist: numpy>=1.26.0
+Requires-Dist: polars>=1.19.0
+Requires-Dist: scipy>=1.11.0
+Description-Content-Type: text/markdown
+
+# dysonsphere
+
+An Altair configuration wrapper with perceptually uniform palettes and chart utilities for publication-ready figures.
+
+*This is a personal project under active development, so there may be breaking changes between minor versions.*
+
+![thumbnail](https://raw.githubusercontent.com/dkkung/dysonsphere/main/docs/thumbnail_light.png)
+
+## Installation
+
+```sh
+# uv
+uv pip install dysonsphere
+
+# pip
+pip install dysonsphere
+```
+
+Requires Python 3.11+. Dependencies: `altair`, `numpy`, `polars`, `scipy`.
+
+---
+
+## Quick start
+
+```python
+import altair as alt
+import polars as pl
+import dysonsphere as theme  # or: import dysonsphere
+
+theme.options(chartWidth=300, chartHeight=200)
+
+chart = (
+    alt.Chart(df)
+    .mark_point()
+    .encode(
+        x=alt.X("x:Q"),
+        y=alt.Y("y:Q"),
+        color=alt.Color("y:Q", scale=alt.Scale(range=theme.palette("blues"))),
+    )
+)
+
+theme.save(chart, "plots/myplot")
+# writes: plots/myplot_light.png, plots/myplot_light.svg
+#         plots/myplot_dark.png,  plots/myplot_dark.svg
+#         plots/myplot_vegalite.json
+```
+
+---
+
+## dysonsphere.options()
+
+**Call before building any Altair charts to configure global theme defaults.**
+
+```python
+theme.options()  # apply defaults
+
+theme.options(   # custom configuration
+    chartWidth=400,
+    chartHeight=250,
+    fontSize=8,
+    grid=True,
+    palette="blues",
+)
+```
+
+| Parameter | Default | Description |
+|---|---|---|
+| `angledX` | `False` | Angle x-axis labels 45° |
+| `axisOffset` | `tickSize` | Distance between axis line and data area |
+| `axisWidth` | `0.25` | Stroke width of axes, ticks, and rules |
+| `bandPadding` | `0.1` | Inner and outer padding for ordinal bands |
+| `chartFill` | `"white"` | Background fill of the entire chart |
+| `chartHeight` | `100` | Default chart height in pixels |
+| `chartWidth` | `100` | Default chart width in pixels |
+| `closed` | auto | Draw a border around the plot area. Auto-enabled when `viewFill` is set |
+| `darkmode` | `False` | Invert text and axis colors for dark backgrounds |
+| `dashedLine` | `False` | Render line marks dashed |
+| `dashedRule` | `True` | Render rule marks dashed |
+| `dashedWidth` | `[2, 2]` | Dash/gap pattern `[dash, gap]` in pixels |
+| `font` | `"HelveticaNeue"` | Font family for all labels and titles |
+| `fontSize` | `7` | Font size in points |
+| `fontWeight` | `400` | Font weight: 300 = light, 400 = normal, 700 = bold |
+| `grid` | `False` | Show axis grid lines |
+| `gridColor` | `"darkGray"` | Grid line color |
+| `legend` | `True` | Show legends |
+| `legendOffset` | `tickSize` | Distance between legend and chart edge |
+| `legendStroke` | `False` | Draw a border around the legend box |
+| `markFill` | `"black"` | Default fill color for marks |
+| `markFillOpacity` | `1.0` | Default mark fill opacity |
+| `markSize` | `min(W, H) × 0.1` | Mark size; for points, this is area in sq px |
+| `markStroke` | `"black"` | Default stroke color for marks |
+| `markStrokeOpacity` | `1` | Default mark stroke opacity |
+| `palette` | `None` | Default color scheme applied to category, diverging, heatmap, and ramp scales. Accepts a key from `colors` or a raw list |
+| `strokeCap` | `"round"` | Stroke end cap: `"butt"`, `"round"`, or `"square"` |
+| `ticks` | `True` | Show axis ticks |
+| `tickSize` | `5` | Tick length in pixels |
+| `transparentBackground` | `False` | Transparent chart background (overrides `chartFill`) |
+| `verticalY` | `False` | Rotate y-axis labels 90° |
+| `viewFill` | `None` | Fill color of the plot area only. Setting this auto-enables `closed` |
+| `xTicks` | `True` | Show ticks on the x-axis |
+| `yTicks` | `True` | Show ticks on the y-axis |
+
+---
+
+## Palettes
+
+All custom palettes are built in [Oklab](https://bottosson.github.io/posts/oklab/) (Ottosson, *A perceptual color space for image processing*, 2020) for perceptual uniformity. They are stored in `dysonsphere.colors`, a plain `dict[str, list[str]]` mapping palette names to 12-stop hex lists (13 stops for diverging palettes).
+
+### Accessing palettes
+
+```python
+from dysonsphere.palettes import colors
+
+blues = colors["blues"]   # list of 12 hex strings, light → dark
+```
+
+### dysonsphere.palette()
+
+Samples a slice or subset from any named palette.
+
+```python
+theme.palette("blues")                     # all 12 stops
+theme.palette("blues", n=5)                # 5 evenly-spaced stops
+theme.palette("blues", start=3)            # stops 3–11
+theme.palette("blues", end=6, step=2)      # indices 0, 2, 4, 6
+theme.palette("blues", n=4, reverse=True)  # reversed
+```
+
+| Parameter | Default | Description |
+|---|---|---|
+| `name` | required | Key in `colors` |
+| `n` | `None` | Return `n` evenly-spaced stops (overrides `step`) |
+| `start` | `0` | Index of the first stop to include |
+| `end` | last | Index of the last stop to include (inclusive) |
+| `step` | `1` | Step between indices (used when `n` is not set) |
+| `reverse` | `False` | Reverse the returned list |
+
+### Theme defaults
+
+When no explicit `scale=` is set on a color encoding, Vega-Lite falls back to the theme's range defaults:
+
+| Range type | Default palette | Used for |
+|---|---|---|
+| `category` | `blues` (even indices: 0, 2, 4, 6, 8, 10) | Nominal/unordered groups |
+| `ordinal` | `blues` | Ordered discrete values |
+| `ramp` | `blues` | Sequential continuous (legend ramps) |
+| `heatmap` | `blues` | Rect/heatmap marks |
+| `diverging` | `redsblues` | Diverging scales |
+
+Setting `theme.options(palette="mypalette")` overrides all five types simultaneously.
+
+### Available palettes
+
+See the [palette gallery](https://dkkung.github.io/dysonsphere/) for a visual overview of all palettes, or open `docs/index.html` locally.
+
+**Sequential — Single-hue** (12 stops, light → dark):
+`blues`, `greens`, `purples`, `lavenders`, `violets`, `greys`, `reds`, `rose`, `oranges`, `browns`, `yellows`, `cyans`, `magentas`, `neongreens`
+
+**Sequential — Single-hue 2** (12 stops, deeper saturation built with Oklab arc-length resampling):
+`blues2`, `greens2`, `purples2`, `lavenders2`, `violets2`, `greys2`, `reds2`, `roses2`, `oranges2`, `browns2`, `yellows2`, `cyans2`, `magentas2`, `neongreens2`
+
+**Sequential — Multi-hue** (12 stops, two or more hues blended in Oklab):
+`yellowgreen`, `ember`, `dusk`, `shoal`, `moss`, `GnBu`, `YlGnBu`, `candy`, `lagoon`, `bluestlagoon`, `bluerlagoon`, `bluelagoon`
+
+**Diverging** (13 stops, exact-white pivot at stop 6):
+`RdBu`, `RdYlBu`, `PuGn`, `MgGn`, `PkTe`, `GdBu`, `BrTe`, `BrGn`
+
+**Diverging — Sequential pairs** (13 stops, one sequential hue per arm):
+`greensblues`, `redsblues`, `redsgreens`, `redscyans`, `redslavenders`, `redsviolets`, `redsneongreens`, `rosesblues`, `rosescyans`, `rosesgreens`, `rosesneongreens`, `orangesblues`, `orangescyans`, `orangespurples`, `orangeslavenders`, `orangesviolets`, `orangesneongreens`, `yellowsblues`, `yellowspurples`, `yellowslavenders`, `brownsblues`, `brownsgreens`, `brownscyans`, `brownsneongreens`, `magentasneongreens`, `magentasgreens`, `magentasblues`, `magentascyans`, `violetsoranges`, `violetsyellows`, `purplesgreens`, `purplesblues`, `purplesneongreens`, `lavendersgreens`, `lavendersblues`, `lavendersneongreens`, `cyanspurples`, `cyanslavenders`, `cyansviolets`, `greysblues`, `greysreds`, `greysgreens`, `greyscyans`, `greysyellows`, `greysoranges`, `greysmagentas`, `greysviolets`, `greysneongreens`, `greyspurples`, `greyslavender`, `greysrose`
+
+**Discrete:**
+`nucleotides` (5 colors: A, T, G, C, U), `proteins` (8 biochemical groups: hydrophobic, aromatic, positive, negative, polar, proline, glycine, cysteine)
+
+**Matplotlib ported** (prefixed with `mpl_`):
+`mpl_viridis`, `mpl_plasma`, `mpl_inferno`, `mpl_magma`, `mpl_cividis`, `mpl_turbo`, `mpl_Blues`, `mpl_Greens`, `mpl_Greys`, `mpl_Oranges`, `mpl_Purples`, `mpl_Reds`, `mpl_YlGnBu`, `mpl_YlOrBr`, `mpl_YlOrRd`, and more.
+
+**cmocean ported** (prefixed with `cmocean_`):
+`cmocean_algae`, `cmocean_amp`, `cmocean_balance`, `cmocean_curl`, `cmocean_deep`, `cmocean_delta`, `cmocean_dense`, `cmocean_diff`, `cmocean_gray`, `cmocean_haline`, `cmocean_ice`, `cmocean_matter`, `cmocean_oxy`, `cmocean_phase`, `cmocean_rain`, `cmocean_solar`, `cmocean_speed`, `cmocean_tarn`, `cmocean_tempo`, `cmocean_thermal`, `cmocean_topo`, `cmocean_turbid`
+
+---
+
+## Saving charts
+
+```python
+theme.save(chart, "plots/myplot")
+# writes: plots/myplot_light.png, plots/myplot_light.svg
+#         plots/myplot_dark.png,  plots/myplot_dark.svg
+#         plots/myplot_vegalite.json
+```
+
+Produces light and dark PNG and SVG files from a single call. SVG output is post-processed to flatten Vega's redundant `<g>` wrappers, making it easier to navigate in Illustrator. A Vega-Lite JSON spec is also saved by default for full reproducibility.
+
+```python
+theme.save(chart, "myplot", ppi=1200)               # default PPI; reduce for faster exports
+theme.save(chart, "myplot", save_vega_spec=False)    # skip the JSON spec
+theme.save(chart, "myplot", description="Figure 1")  # embed a description in the SVG
+```
+
+---
+
+## Custom marks
+
+### dysonsphere.mark_violin()
+
+Violin plot with an embedded boxplot.
+
+```python
+theme.options(chartWidth=300)
+palette = theme.palette("lavenders", n=len(CATEGORIES))
+
+chart = theme.mark_violin(df, "group", "value", CATEGORIES, palette=palette)
+theme.save(chart, "violin")
+```
+
+| Parameter | Default | Description |
+|---|---|---|
+| `df` | required | Polars DataFrame |
+| `x_col` | required | Grouping column name |
+| `y_col` | required | Value column name |
+| `categories` | required | Ordered list of group labels |
+| `palette` | `None` | Single color or list of colors for violin fills |
+| `boxplot_size` | `markSize × 0.8` | Boxplot box width in pixels |
+| `boxplot_color` | `"black"` | Boxplot fill color |
+| `fillOpacity` | theme default | Violin fill opacity |
+| `stroke` | `None` | Violin outline color (`None` = no outline) |
+| `strokeWidth` | theme default | Violin outline width |
+| `legend` | `False` | Show a color legend |
+| `angledX` | theme default | Angle x-axis labels |
+| `steps` | `200` | KDE grid resolution per group |
+
+### dysonsphere.mark_strip()
+
+Jittered or beeswarm points with a median tick and optional mean ± error bars.
+
+```python
+chart = theme.mark_strip(df, "group", "value", CATEGORIES)
+chart = theme.mark_strip(df, "group", "value", CATEGORIES, scatter="beeswarm")
+```
+
+| Parameter | Default | Description |
+|---|---|---|
+| `scatter` | `"jitter"` | `"jitter"` (fast, random Gaussian) or `"beeswarm"` (collision-avoidance) |
+| `palette` | `None` | List of colors for points |
+| `point_size` | theme `markSize` | Point size in sq px |
+| `jitter_scale` | `4.0` | Jitter standard deviation in pixels |
+| `errorbars` | `True` | Show mean ± error bars |
+| `errorbar_extent` | `"sem"` | `"sem"` or `"sd"` |
+
+---
+
+## Statistical annotations
+
+Add a p-value bracket between two groups using `dysonsphere.pvalue_layer()`. Combine with any chart using `+`.
+
+```python
+ann = theme.pvalue_layer(
+    df, "group", "value", "Control", "Drug A",
+    test="mannwhitneyu",
+    categories=["Control", "Drug A", "Drug B"],
+    chartWidth=300,
+    y=210,
+)
+chart + ann
+```
+
+From a pre-computed p-value:
+
+```python
+ann = theme.pvalue_layer(
+    group1="Control", group2="Drug A",
+    pvalue=0.023, y=210,
+    categories=CATEGORIES,
+    chartWidth=300,
+)
+```
+
+| Parameter | Default | Description |
+|---|---|---|
+| `df` | `None` | Polars DataFrame (required unless `pvalue` and `y` are both provided) |
+| `x_col`, `y_col` | `None` | Column names for groups and values |
+| `group1`, `group2` | required | Group labels to compare |
+| `test` | `"mannwhitneyu"` | Statistical test: `"mannwhitneyu"`, `"ttest_ind"`, `"ttest_rel"`, `"wilcoxon"`, `"tukey_hsd"` |
+| `pvalue` | `None` | Pre-computed p-value (skips the test) |
+| `correction` | `None` | `"bonferroni"` or `None` |
+| `n_comparisons` | `1` | Number of comparisons for Bonferroni correction |
+| `y` | auto | Y position of the bracket in data units |
+| `y_pad` | `5` | Padding above the group max when `y` is auto-placed |
+| `style` | `"line"` | `"line"` (bar only) or `"bracket"` (bar + end ticks) |
+| `categories` | inferred | Ordered list of all x-axis categories |
+| `chartWidth` | theme default | Chart width used to compute text x position |
+| `reverse` | `False` | Flip the annotation below the bar |
+| `decimals` | `3` | Decimal places in the p-value label |
+
+---
+
+## Data transforms
+
+### Jitter
+
+Adds random Gaussian x-offsets to each row, useful for strip plots.
+
+```python
+df = theme.add_jitter_offsets(df, scale=5)
+
+alt.Chart(df).mark_circle().encode(
+    x=alt.X("group:N"),
+    y=alt.Y("value:Q"),
+    xOffset=alt.XOffset("jitter_x:Q"),
+)
+```
+
+| Parameter | Default | Description |
+|---|---|---|
+| `scale` | `5.0` | Standard deviation of jitter in pixels |
+| `out_col` | `"jitter_x"` | Output column name |
+| `seed` | `20220701` | Random seed |
+
+### Beeswarm
+
+Computes collision-avoiding x-offsets per group. Better than jitter for small n, but slower.
+
+```python
+df = theme.add_beeswarm_offsets(
+    df,
+    y_col="value",
+    group_by=["group"],
+    height_px=200,
+    markSize=10,
+)
+```
+
+| Parameter | Default | Description |
+|---|---|---|
+| `y_col` | required | Value column |
+| `group_by` | required | Column(s) defining each beeswarm group |
+| `height_px` | theme `chartHeight` | Chart height in pixels |
+| `markSize` | `10` | Point size (area in sq px) |
+| `out_col` | `"beeswarm_x"` | Output column name |
+
+---
+
+## Development
+
+### Building palettes
+
+`scripts/build/build_palettes.py` documents the Oklab recipes for all custom palette families and prints updated hex literals to stdout. Use this to calibrate or extend palettes.
+
+```sh
+# uv
+uv run python scripts/build/build_palettes.py
+
+# pip
+python scripts/build/build_palettes.py
+```
+
+The four recipes are:
+
+1. **Sequential single-hue** — fix hue; sweep L from light to dark with C = `frac × Cmax(L, hue)`; arc-length resample to 12 stops.
+2. **Sequential multi-hue** — interpolate `(L, hue)` between keyframes; same chroma and arc-length logic.
+3. **Diverging** — two arms meeting at an exact-white pivot; 13 stops so the white center lands exactly on the V-corner.
+4. **Chroma-scaling** — preserve L, scale `(a, b)` by a constant to derive lighter variants.
+
+Palette hex values live in `dysonsphere/palettes.py` as plain lists — no color math runs at import time.
+
+### Building the gallery
+
+```sh
+# uv
+uv run python scripts/build/build_gallery.py
+
+# pip
+python scripts/build/build_gallery.py
+```
+
+Writes `docs/index.html`. Open in a browser to browse all palettes across 11 chart types.
+
+### Exporting swatches for Adobe Illustrator
+
+```sh
+# uv
+uv run python scripts/build/build_swatches_for_illustrator.py
+
+# pip
+python scripts/build/build_swatches_for_illustrator.py
+```
+
+Generates `scripts/import_palettes_to_illustrator.jsx`. To import into Illustrator:
+
+1. Open or create a document in Adobe Illustrator.
+2. Go to **File > Scripts > Other Script...**
+3. Select `scripts/import_palettes_to_illustrator.jsx`.
+4. All palettes are added as named swatch groups in the Swatches panel.
+
+Re-run this script after adding or modifying palettes in `dysonsphere/palettes.py`.
