+# counted-float
+
+This Python package provides functionality for...
+- **counting floating point operations** (FLOPs) of numerical algorithms implemented in plain Python, optionally weighted by their relative cost of execution
+- **running benchmarks** to estimate the relative cost of executing various floating-point operations (requires `numba` optional dependency for achieving accurate results)
+
+The target application area is evaluation of research prototypes of numerical algorithms where (weighted) flop counting can be
+useful for estimating total computational cost, in cases where benchmarking a compiled version (C, Rust, ...) is not
+feasible or desirable.
+
+# 1. Installation
+
+Use you favorite package manager such as `uv` or `pip`:
+
+```
+pip install counted-float           # install without numba optional dependency
+pip install counted-float[numba]    # install with numba optional dependency
+```
+Numba is optional due to its relatively large size (40-50MB, including llvmlite), but without it, benchmarks will
+not be reliable (but will still run, but not in jit-compiled form).
+
+NOTE: the `cli` optional dependency is only useful when installing the code as a tool using e.g. `uv` or `pipx` (see below)
+
+# 2. Counting Flops
+
+## 2.1. CountedFloat class
+
+In order to instrument all floating point operations with counting functionality,
+the `CountedFloat` class was implemented, which is a drop-in replacement for the built-in `float` type.
+The `CountedFloat` class is a subclass of `float` and is "contagious", meaning that it will automatically
+ensure results of math operations where at least one operand is a `CountedFloat` will also be a `CountedFloat`.
+This way we ensure flop counting is a 'closed system'.
+
+On top of this, we monkey-patch the `math` module to ensure that all math operations
+that require counting (`sqrt`, `log2`, `pow`, ...) are also instrumented.
+
+**Example 1**:
+
+```python
+from counted_float import CountedFloat
+
+cf = CountedFloat(1.3)
+f = 2.8
+
+result = cf + f  # result = CountedFloat(4.1)
+
+is_float_1 = isinstance(cf, float)  # True
+is_float_2 = isinstance(result, float)  # True
+```
+
+**Example 2**:
+
+```python
+import math
+from counted_float import CountedFloat
+
+cf1 = CountedFloat(0.81)
+
+s = math.sqrt(cf1)  # s = CountedFloat(0.9)
+is_float = isinstance(s, float)  # True
+```
+
+## 2.2. FLOP counting context managers
+
+Once we use the `CountedFloat` class, we can use the available context managers to count the number of
+flops performed by `CountedFloat` objects.
+
+**Example 1**:  _basic usage_
+```python
+from counted_float import CountedFloat, FlopCountingContext
+
+cf1 = CountedFloat(1.73)
+cf2 = CountedFloat(2.94)
+
+with FlopCountingContext() as ctx:
+    _ = cf1 * cf2
+    _ = cf1 + cf2
+
+counts = ctx.flop_counts()   # {FlopType.MUL: 1, FlopType.ADD: 1}
+counts.total_count()         # 2
+```
+
+**Example 2**:  _pause counting 1_
+
+```python
+from counted_float import CountedFloat, FlopCountingContext
+
+cf1 = CountedFloat(1.73)
+cf2 = CountedFloat(2.94)
+
+with FlopCountingContext() as ctx:
+    _ = cf1 * cf2
+    ctx.pause()
+    _ = cf1 + cf2   # will be executed but not counted
+    ctx.resume()
+    _ = cf1 - cf2
+
+counts = ctx.flop_counts()   # {FlopType.MUL: 1, FlopType.SUB: 1}
+counts.total_count()         # 2
+```
+
+**Example 3**:  _pause counting 2_
+
+```python
+from counted_float import CountedFloat, FlopCountingContext, PauseFlopCounting
+
+cf1 = CountedFloat(1.73)
+cf2 = CountedFloat(2.94)
+
+with FlopCountingContext() as ctx:
+    _ = cf1 * cf2
+    with PauseFlopCounting():
+        _ = cf1 + cf2   # will be executed but not counted
+    _ = cf1 - cf2
+
+counts = ctx.flop_counts()   # {FlopType.MUL: 1, FlopType.SUB: 1}
+counts.total_count()         # 2
+```
+
+## 2.3. Weighted FLOP counting
+
+The `counted_float` package contains a set of default, built-in FLOP weights, based on both empirical measurements
+and theoretical estimates of the relative cost of different floating point operations.
+
+See [fpu_data_sources.md](https://github.com/bertpl/counted-float/tree/develop/docs/analysis_methodology.md) for
+rationale behind choice of data sources and methodology.
+
+```
+>>> from counted_float.config import get_active_flop_weights
+>>> get_active_flop_weights().show()
+
+{
+    FlopType.ABS        [abs(x)]        :    1
+    FlopType.MINUS      [-x]            :    1
+    FlopType.COMP       [x<=y]          :    1
+    FlopType.RND        [round]         :    2
+    FlopType.F2I        [float->int]    :    2
+    FlopType.I2F        [int->float]    :    2
+    FlopType.ADD        [x+y]           :    1
+    FlopType.SUB        [x-y]           :    1
+    FlopType.MUL        [x*y]           :    1
+    FlopType.DIV        [x/y]           :    5
+    FlopType.SQRT       [sqrt(x)]       :    6
+    FlopType.CBRT       [cbrt(x)]       :   42
+    FlopType.EXP        [e^x]           :   19
+    FlopType.EXP2       [2^x]           :   29
+    FlopType.EXP10      [10^x]          :   23
+    FlopType.LOG        [log(x)]        :   19
+    FlopType.LOG2       [log2(x)]       :   24
+    FlopType.LOG10      [log10(x)]      :   19
+    FlopType.POW        [x^y]           :   62
+    FlopType.SIN        [sin(x)]        :   32
+    FlopType.COS        [cos(x)]        :   31
+    FlopType.TAN        [tan(x)]        :   34
+}
+```
+These weights will be used by default when extracting total weighted flop costs:
+
+```python
+import math
+from counted_float import CountedFloat, FlopCountingContext
+
+
+cf1 = CountedFloat(1.73)
+cf2 = CountedFloat(2.94)
+
+with FlopCountingContext() as ctx:
+    _ = cf1 + cf2
+    _ = cf1 ** cf2
+    _ = math.log2(cf2)
+
+flop_counts = ctx.flop_counts()
+total_cost = flop_counts.total_weighted_cost()  # 1 + 62 + 24 = 87
+```
+Note that the `total_weighted_cost` method will use the default flop weights as returned by `get_flop_weights()`.  This can be
+overridden by either configuring different flop weights (see next section) or by setting the `weights` argument of the `total_weighted_cost()` method.
+
+
+## 2.4. Configuring FLOP weights
+
+We showed earlier that the `get_flop_weights()` function returns the default FLOP weights.  We can change this by
+using the `set_flop_weights()` function, which takes a `FlopWeights` object as an argument.  This way we can configure
+flop weights that might be obtained using benchmarks run on the target hardware (see later sections).
+
+```python
+from counted_float.config import set_active_flop_weights
+from counted_float import FlopWeights
+
+set_active_flop_weights(weights=FlopWeights(...))  # insert own weights here
+```
+## 2.5. Inspecting built-in data
+
+### 2.5.1. Default, pre-aggregated flop weights
+
+Built-in flop weights can be inspected using the following functions:
+
+```python
+from counted_float.config import get_default_consensus_flop_weights
+
+>>> get_default_consensus_flop_weights(rounded=False).show()
+
+{
+    FlopType.ABS        [abs(x)]        :   0.63673
+    FlopType.MINUS      [-x]            :   0.64396
+    FlopType.COMP       [x<=y]          :   1.20756
+    FlopType.RND        [round]         :   1.54041
+    FlopType.F2I        [float->int]    :   1.99099
+    FlopType.I2F        [int->float]    :   1.84601
+    FlopType.ADD        [x+y]           :   1.00000
+    FlopType.SUB        [x-y]           :   1.00586
+    FlopType.MUL        [x*y]           :   1.37238
+    FlopType.DIV        [x/y]           :   5.07465
+    FlopType.SQRT       [sqrt(x)]       :   5.90559
+    FlopType.CBRT       [cbrt(x)]       :  42.39375
+    FlopType.EXP        [e^x]           :  18.58228
+    FlopType.EXP2       [2^x]           :  28.88672
+    FlopType.EXP10      [10^x]          :  22.86839
+    FlopType.LOG        [log(x)]        :  18.89135
+    FlopType.LOG2       [log2(x)]       :  24.34792
+    FlopType.LOG10      [log10(x)]      :  18.55085
+    FlopType.POW        [x^y]           :  61.79155
+    FlopType.SIN        [sin(x)]        :  31.91490
+    FlopType.COS        [cos(x)]        :  30.79295
+    FlopType.TAN        [tan(x)]        :  34.37970
+}
+```
+
+The default weights that are configured out-of-the-box in the package are the integer-rounded `consensus` weights.
+
+### 2.5.2. Custom-aggregated flop weights
+
+We can retrieve built-in flop weights in a more fine-grained manner, by custom filtering and the aggregating them with
+the geometric mean.
+
+```python
+from counted_float.config import get_builtin_flop_weights
+
+>>> get_builtin_flop_weights(key_filter="arm").show()
+
+{
+    FlopType.ABS        [abs(x)]        :   0.97313
+    FlopType.MINUS      [-x]            :   0.99098
+    FlopType.COMP       [x<=y]          :   1.03987
+    FlopType.RND        [round]         :   1.35111
+    FlopType.F2I        [float->int]    :   1.52648
+    FlopType.I2F        [int->float]    :   1.63320
+    FlopType.ADD        [x+y]           :   1.00000
+    FlopType.SUB        [x-y]           :   1.00058
+    FlopType.MUL        [x*y]           :   1.44952
+    FlopType.DIV        [x/y]           :   5.00897
+    FlopType.SQRT       [sqrt(x)]       :   5.15597
+    FlopType.CBRT       [cbrt(x)]       :  39.30448
+    FlopType.EXP        [e^x]           :  17.22817
+    FlopType.EXP2       [2^x]           :  15.82232
+    FlopType.EXP10      [10^x]          :  21.20195
+    FlopType.LOG        [log(x)]        :  17.51472
+    FlopType.LOG2       [log2(x)]       :  18.32529
+    FlopType.LOG10      [log10(x)]      :  17.19903
+    FlopType.POW        [x^y]           :  47.63289
+    FlopType.SIN        [sin(x)]        :  29.58923
+    FlopType.COS        [cos(x)]        :  28.54904
+    FlopType.TAN        [tan(x)]        :  31.87442
+}
+```
+
+# 3. Benchmarking
+
+If the package is installed with the optional `numba` dependency, it provides the ability to micro-benchmark
+floating point operations as follows:
+
+```
+>>> from counted_float.benchmarking import run_flops_benchmark
+>>> results = run_flops_benchmark()
+
+Running FLOPS benchmarks using counted-float 0.9.5 ...
+(Expected duration: ~87.8 seconds)
+
+baseline                           : wwwwwwwwwwwwwww.........................   [  74.43 ns ±  2.6% |   302 cpu cycles ±  2.6% ]  /  1000 iterations
+add                                : wwwwwwwwwwwwwww.........................   [ 662.35 ns ±  0.2% | 2.69K cpu cycles ±  0.2% ]  /  1000 iterations
+add_minus                          : wwwwwwwwwwwwwww.........................   [   1.23 µs ±  0.2% | 4.98K cpu cycles ±  0.2% ]  /  1000 iterations
+add_abs                            : wwwwwwwwwwwwwww.........................   [   1.23 µs ±  0.4% | 4.99K cpu cycles ±  0.4% ]  /  1000 iterations
+add_add                            : wwwwwwwwwwwwwww.........................   [   1.29 µs ±  0.2% | 5.23K cpu cycles ±  0.2% ]  /  1000 iterations
+add_sub                            : wwwwwwwwwwwwwww.........................   [   1.29 µs ±  0.2% | 5.23K cpu cycles ±  0.2% ]  /  1000 iterations
+add_round                          : wwwwwwwwwwwwwww.........................   [   1.44 µs ±  0.1% | 5.84K cpu cycles ±  0.1% ]  /  1000 iterations
+add_sqrt                           : wwwwwwwwwwwwwww.........................   [   3.96 µs ±  0.2% | 16.1K cpu cycles ±  0.2% ]  /  1000 iterations
+add_cbrt                           : wwwwwwwwwwwwwww.........................   [  25.42 µs ±  0.2% |  103K cpu cycles ±  0.2% ]  /  1000 iterations
+add_log                            : wwwwwwwwwwwwwww.........................   [  11.69 µs ±  0.3% | 47.4K cpu cycles ±  0.3% ]  /  1000 iterations
+add_log_exp                        : wwwwwwwwwwwwwww.........................   [  22.57 µs ±  0.1% | 91.5K cpu cycles ±  0.1% ]  /  1000 iterations
+add_log2                           : wwwwwwwwwwwwwww.........................   [  12.00 µs ±  0.2% | 48.7K cpu cycles ±  0.2% ]  /  1000 iterations
+add_log2_exp2                      : wwwwwwwwwwwwwww.........................   [  22.48 µs ±  0.2% | 91.2K cpu cycles ±  0.2% ]  /  1000 iterations
+add_log10                          : wwwwwwwwwwwwwww.........................   [  11.50 µs ±  0.2% | 46.6K cpu cycles ±  0.2% ]  /  1000 iterations
+add_log10_exp10                    : wwwwwwwwwwwwwww.........................   [  24.68 µs ±  0.2% |  100K cpu cycles ±  0.2% ]  /  1000 iterations
+add_sin                            : wwwwwwwwwwwwwww.........................   [  18.64 µs ±  0.3% | 75.6K cpu cycles ±  0.3% ]  /  1000 iterations
+add_cos                            : wwwwwwwwwwwwwww.........................   [  18.92 µs ±  0.3% | 76.7K cpu cycles ±  0.3% ]  /  1000 iterations
+add_tan                            : wwwwwwwwwwwwwww.........................   [  20.91 µs ±  0.2% | 84.8K cpu cycles ±  0.2% ]  /  1000 iterations
+pow                                : wwwwwwwwwwwwwww.........................   [  24.12 µs ±  0.3% | 97.8K cpu cycles ±  0.3% ]  /  1000 iterations
+pow_pow                            : wwwwwwwwwwwwwww.........................   [  48.15 µs ±  0.2% |  195K cpu cycles ±  0.2% ]  /  1000 iterations
+sub                                : wwwwwwwwwwwwwww.........................   [ 661.55 ns ±  0.2% | 2.68K cpu cycles ±  0.2% ]  /  1000 iterations
+sub_sub                            : wwwwwwwwwwwwwww.........................   [   1.29 µs ±  0.2% | 5.24K cpu cycles ±  0.2% ]  /  1000 iterations
+mul                                : wwwwwwwwwwwwwww.........................   [ 961.78 ns ±  0.2% | 3.90K cpu cycles ±  0.2% ]  /  1000 iterations
+mul_mul                            : wwwwwwwwwwwwwww.........................   [   1.92 µs ±  0.2% | 7.78K cpu cycles ±  0.2% ]  /  1000 iterations
+div                                : wwwwwwwwwwwwwww.........................   [   2.45 µs ±  0.2% | 9.92K cpu cycles ±  0.2% ]  /  1000 iterations
+div_div                            : wwwwwwwwwwwwwww.........................   [   5.00 µs ±  0.2% | 20.3K cpu cycles ±  0.2% ]  /  1000 iterations
+lte_addsub                         : wwwwwwwwwwwwwww.........................   [   1.71 µs ±  0.2% | 6.94K cpu cycles ±  0.2% ]  /  1000 iterations
+
+>>> results.flop_weights.show()
+
+{
+    FlopType.ABS        [abs(x)]        :   0.90556
+    FlopType.MINUS      [-x]            :   0.90089
+    FlopType.COMP       [x<=y]          :   1.67297
+    FlopType.RND        [round]         :   1.24118
+    FlopType.ADD        [x+y]           :   1.00000
+    FlopType.SUB        [x-y]           :   0.99928
+    FlopType.MUL        [x*y]           :   1.52656
+    FlopType.DIV        [x/y]           :   4.06589
+    FlopType.SQRT       [sqrt(x)]       :   5.26487
+    FlopType.CBRT       [cbrt(x)]       :  39.49190
+    FlopType.EXP        [e^x]           :  17.34508
+    FlopType.EXP2       [2^x]           :  16.70475
+    FlopType.EXP10      [10^x]          :  21.03351
+    FlopType.LOG        [log(x)]        :  17.59412
+    FlopType.LOG2       [log2(x)]       :  18.08932
+    FlopType.LOG10      [log10(x)]      :  17.27955
+    FlopType.POW        [x^y]           :  38.32044
+    FlopType.SIN        [sin(x)]        :  28.67006
+    FlopType.COS        [cos(x)]        :  29.11818
+    FlopType.TAN        [tan(x)]        :  32.28703
+    FlopType.F2I        [float->int]    :       nan
+    FlopType.I2F        [int->float]    :       nan
+}
+```
+
+## 4. Installing the package as a command-line tool
+
+An alternative way of using (parts) of the functionality is installing the package as a stand-alone command-line tool
+using `uv` or `pipx`:
+
+```
+uv tool install git+https://github.com/bertpl/counted-float@main[numba,cli]         # latest official release
+uv tool install git+https://github.com/bertpl/counted-float@develop[numba,cli]      # or latest develop version
+```
+This installs the `counted_float` command-line tool, which can be used to e.g. run flops benchmarks.
+
+## 4.1. Running benchmarks
+
+```
+counted_float benchmark
+```
+after which the results will be shown as .json.
+
+## 4.2. Show built-in data
+
+```
+[~] counted_float show-data
+
+                                                       ABS     MINUS       ADD       SUB      COMP       MUL       RND       I2F       F2I       DIV      SQRT     LOG10       EXP       LOG     EXP10      LOG2      EXP2       COS       SIN       TAN      CBRT       POW
+ALL                                                   0.64      0.64      1.00      1.01      1.21      1.37      1.54      1.85      1.99      5.07      5.91     18.55     18.58     18.89     22.87     24.35     28.89     30.79     31.91     34.38     42.39     61.79
+ ├─arm                                                0.97      0.99      1.00      1.00      1.04      1.45      1.35      1.63      1.53      5.01      5.16     17.20     17.23     17.51     21.20     18.33     15.82     28.55     29.59     31.87     39.30     47.63
+ │  ├─v8_x                                            0.92      0.97      1.00      1.00      1.12      1.35      1.25      1.94      1.58      3.88      4.09     16.56     16.59     16.86     20.41     17.64     15.23     27.48     28.49     30.69     37.84     45.86
+ │  │  ├─benchmarks                                   0.85      0.95      1.00      1.00      1.26      1.22      1.05        /         /       2.93      3.12     15.11     15.14     15.39     18.63     16.10     13.90     25.09     26.00     28.01     34.54     41.85
+ │  │  │  ├─m3_max_macbook_pro_16                     0.80      1.00      1.00      1.01      1.01      1.01      0.89        /         /       2.19      1.85        /         /         /         /      14.40     11.59        /         /         /         /      46.48
+ │  │  │  └─m3_max_macbook_pro_16_v2                  0.90      0.90      1.00      1.00      1.58      1.47      1.24        /         /       3.93      5.25     17.23     17.26     17.55     21.24     18.01     16.68     28.60     29.64     31.93     39.38     37.68
+ │  │  └─specs                                        1.00      1.00      1.00      1.00      1.00      1.50      1.50      2.12      1.73      5.12      5.37        /         /         /         /         /         /         /         /         /         /         /
+ │  │     ├─arm_v8_cortex_a76                         1.00      1.00      1.00      1.00      1.00      1.50      1.50      3.00      2.00      5.12      5.45        /         /         /         /         /         /         /         /         /         /         /
+ │  │     ├─arm_v9_cortex_n1                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      3.00      2.00      5.12      5.45        /         /         /         /         /         /         /         /         /         /         /
+ │  │     ├─arm_v9_cortex_v1                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  │     └─arm_v9_cortex_x1                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  ├─v9_0                                            1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  │  └─specs                                        1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  │     ├─arm_v9_cortex_n2                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  │     ├─arm_v9_cortex_v2                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  │     ├─arm_v9_cortex_x2                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  │     └─arm_v9_cortex_x3                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
+ │  └─v9_2                                            1.00      1.00      1.00      1.00      1.00      1.50      1.31      1.50      1.50      6.33      6.33        /         /         /         /         /         /         /         /         /         /         /
+ │     └─specs                                        1.00      1.00      1.00      1.00      1.00      1.50      1.31      1.50      1.50      6.33      6.33        /         /         /         /         /         /         /         /         /         /         /
+ │        ├─arm_v9_cortex_v3                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      6.50      6.50        /         /         /         /         /         /         /         /         /         /         /
+ │        ├─arm_v9_cortex_x4                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      6.50      6.50        /         /         /         /         /         /         /         /         /         /         /
+ │        └─arm_v9_cortex_x925                        1.00      1.00      1.00      1.00      1.00      1.50      1.00      1.50      1.50      6.00      6.00        /         /         /         /         /         /         /         /         /         /         /
+ └─x86                                                0.42      0.42      1.00      1.01      1.40      1.30      1.76      2.09      2.60      5.14      6.76        /         /         /         /      32.35     52.74        /         /         /         /      80.16
+    ├─amd                                             0.44      0.44      1.00      1.01      1.81      1.18      1.02      2.19      2.61      4.85      6.94        /         /         /         /      32.91    173.48        /         /         /         /      94.73
+    │  ├─2017_zen1                                    0.46      0.48      1.00      1.04      1.57      1.14      1.14      2.22      3.51      4.46      5.06        /         /         /         /      32.94    173.63        /         /         /         /      94.81
+    │  │  ├─analysis_uops_info_zen1+                  0.33      0.33      1.00      1.00      2.33      1.33      0.67      2.11      3.33      4.33      6.67        /         /         /         /         /         /         /         /         /         /         /
+    │  │  └─benchmark_ryzen_1700x                     0.64      0.69      1.00      1.08      1.06      0.97      1.97        /         /       4.58      3.83        /         /         /         /      34.68    182.82        /         /         /         /      99.82
+    │  ├─2020_zen3                                    0.33      0.33      1.00      1.00      1.97      1.01      0.76      2.01      2.45      4.42      6.67        /         /         /         /         /         /         /         /         /         /         /
+    │  │  ├─analysis_agner_fog_r7_5800x               0.33      0.33      1.00      1.00      1.67        /       1.00      2.33      2.00      4.50      6.67        /         /         /         /         /         /         /         /         /         /         /
+    │  │  └─analysis_uops_info_zen3                   0.33      0.33      1.00      1.00      2.33      1.00      0.58      1.73      3.00      4.33      6.67        /         /         /         /         /         /         /         /         /         /         /
+    │  ├─2022_zen4                                    0.33      0.33      1.00      1.00      1.28      1.02      0.83      1.63      2.00      4.33      6.89        /         /         /         /         /         /         /         /         /         /         /
+    │  │  ├─analysis_agner_fog_r9_7900x               0.33      0.33      1.00      1.00      1.33        /       1.00      2.00      2.00      4.33      7.00        /         /         /         /         /         /         /         /         /         /         /
+    │  │  ├─analysis_uops_info_zen4                   0.33      0.33      1.00      1.00      2.33      1.00      0.58      1.63      3.00      4.33      7.00        /         /         /         /         /         /         /         /         /         /         /
+    │  │  └─specs_amd                                 0.33      0.33      1.00      1.00      0.67      1.00      1.00      1.33      1.33      4.33      6.67        /         /         /         /         /         /         /         /         /         /         /
+    │  └─2024_zen5                                    0.71      0.71      1.00      1.00      2.72      1.66      1.50      3.17      2.72      6.50     10.00        /         /         /         /         /         /         /         /         /         /         /
+    │     ├─analysis_agner_fog_r7_9800x3d             1.00      1.00      1.00      1.00      3.00        /       1.50      3.50      3.00      6.50     10.00        /         /         /         /         /         /         /         /         /         /         /
+    │     └─specs_amd                                 0.50      0.50      1.00      1.00        /       1.50      1.50        /         /       6.50     10.00        /         /         /         /         /         /         /         /         /         /         /
+    └─intel                                           0.40      0.40      1.00      1.01      1.09      1.43      3.02      1.99      2.58      5.45      6.59        /         /         /         /      31.80     16.03        /         /         /         /      67.83
+       ├─2017_coffee_lake_gen_8                       0.25      0.25      1.00      1.00      0.74      1.00      2.00      1.41      1.62      3.56      4.29        /         /         /         /         /         /         /         /         /         /         /
+       │  ├─analysis_agner_fog_coffee_lake            0.25      0.25      1.00      1.00        /       1.00      2.00      1.50      1.50      3.37      3.87        /         /         /         /         /         /         /         /         /         /         /
+       │  └─analysis_uops_info_coffee_lake            0.25      0.25      1.00      1.00      0.75      1.00      2.00      1.32      1.75      3.75      4.75        /         /         /         /         /         /         /         /         /         /         /
+       ├─2019_sunny_cove_gen_10                       0.25      0.25      1.00      1.00      0.66      0.98      2.00      1.38      1.66      3.62      4.44        /         /         /         /         /         /         /         /         /         /         /
+       │  ├─analysis_agner_fog_ice_lake               0.25      0.25      1.00      1.00      0.50        /       2.00      1.50      1.50      3.37      3.87        /         /         /         /         /         /         /         /         /         /         /
+       │  ├─analysis_uops_info_ice_lake               0.25      0.25      1.00      1.00      0.75      1.00      2.00      1.32      1.75      3.75      4.75        /         /         /         /         /         /         /         /         /         /         /
+       │  └─analysis_uops_info_tiger_lake             0.25      0.25      1.00      1.00      0.75      1.00      2.00      1.32      1.75      3.75      4.75        /         /         /         /         /         /         /         /         /         /         /
+       ├─2021_golden_cove_gen_12                      0.64      0.64      1.00      1.07      1.39      1.53      3.93      2.54      3.46      7.61      8.07        /         /         /         /      40.46     20.40        /         /         /         /      86.31
+       │  ├─analysis_uops_info_alder_lake_p           0.41      0.41      1.00      1.00      1.22      1.63      3.27      2.16      2.86      6.12      7.76        /         /         /         /         /         /         /         /         /         /         /
+       │  ├─benchmark_core_i7_1265u                   1.28      1.25      1.00      1.21      1.47      1.10      4.65        /         /      10.27      7.54        /         /         /         /      48.46     24.43        /         /         /         /     103.37
+       │  └─specs_intel                               0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
+       ├─2022_raptor_cove_gen_13_14                   0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
+       │  └─specs_intel                               0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
+       └─2023_redwood_cove_ultra_1                    0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
+          └─specs_intel                               0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
+```
+
+# 5. Known limitations
+
+- currently any non-Python-built-in math operations are not counted (e.g. `numpy`)
+- not all Python built-in math operations are counted (e.g. `log`, `log10`, `exp`, `exp10`)
+- flop weights should be taken with a grain of salt and should only provide relative ballpark estimates w.r.t computational complexity.  Production implementations in a compiled language could have vastly differing performance depending on cpu cache sizes, branch prediction misses, compiler optimizations using vector operations (AVX etc...), etc...
+
+# Appendix A - Flop counting / analysis details
+
+This appendix provides detailed information about how each floating-point operation (FLOP) type is counted and analyzed in the `counted-float` package. For each flop type, you will find:
+- Relevant scalar instructions for ARM (v8+) and x86 (SSE2+)
+- Python operations that are counted for this flop type
+- Python operations that are *not* counted for this flop type
+
+## Flop Types
+
+### FlopType.ABS (`abs(x)`)
+- Relevant CPU instructions
+  - **ARM:** `FABS`
+  - **x86:** `ANDPD`
+- **Counted Python operations:** `abs(x)` where `x` is a `CountedFloat`
+- **Not counted:** `numpy.abs`, complex abs, abs on non-CountedFloat
+
+### FlopType.MINUS (`-x`)
+- Relevant CPU instructions
+  - **ARM:** `FNEG`
+  - **x86:** `XORPD`
+- **Counted Python operations:** Unary minus (`-x`) for `CountedFloat`
+- **Not counted:** Negation on non-CountedFloat, numpy negation
+
+### FlopType.COMP (`x<=y`, `x>y`, `x==y`, `x==0.0`, ...)
+- Relevant CPU instructions
+  - **ARM:** `FCMP`
+  - **x86:** `(U)COMISD`
+- **Counted Python operations:** `x == y`, `x != y`, `x <= y`, ... and `min(x,y)`, `max(x,y)` for `CountedFloat`
+- **Not counted:** Comparisons on non-CountedFloat, numpy comparisons
+
+### FlopType.RND (`round`)
+- Relevant CPU instructions
+  - **ARM:** `FRINT`
+  - **x86:** `ROUNDSD`
+- **Counted Python operations:** `round(x, 0)` for `CountedFloat` (returns float)
+- **Not counted:** `numpy.round`, rounding with decimals, rounding on non-CountedFloat
+
+### FlopType.F2I (`float->int`)
+- Relevant CPU instructions
+  - **ARM:** `FCVTZS`
+  - **x86:** `CVTSD2SI`
+- **Counted Python operations:** `int(x)`, `math.floor(x)`, `math.ceil(x)`, `math.trunc(x)`, `round(x)` for `CountedFloat` (returns int)
+- **Not counted:** Conversions on non-CountedFloat, numpy conversions
+
+### FlopType.I2F (`int->float`)
+- Relevant CPU instructions
+  - **ARM:** `SCVTF`
+  - **x86:** `CVTSI2SD`
+- **Counted Python operations:** Construction of `CountedFloat` from int, any binary operation where one operand is an int and the other a `CountedFloat` (e.g., `x + 3`, `3 * x`, etc.)
+- **Not counted:** `float(n)`, unitary operations (e.g. `math.sqrt` on integers -> convert to `CountedFloat` first)
+
+### FlopType.ADD (`x+y`)
+- Relevant CPU instructions
+  - **ARM:** `FADD`
+  - **x86:** `ADDSD`
+- **Counted Python operations:** `x + y` or `y + x` for `CountedFloat`
+- **Not counted:** Addition on non-CountedFloat, numpy addition
+
+### FlopType.SUB (`x-y`)
+- Relevant CPU instructions
+  - **ARM:** `FSUB`
+  - **x86:** `SUBSD`
+- **Counted Python operations:** `x - y` or `y - x` for `CountedFloat`
+- **Not counted:** Subtraction on non-CountedFloat, numpy subtraction
+
+### FlopType.MUL (`x*y`)
+- Relevant CPU instructions
+  - **ARM:** `FMUL`
+  - **x86:** `MULSD`
+- **Counted Python operations:** `x * y` or `y * x` for `CountedFloat`
+- **Not counted:** Multiplication on non-CountedFloat, numpy multiplication
+
+### FlopType.DIV (`x/y`)
+- Relevant CPU instructions
+  - **ARM:** `FDIV`
+  - **x86:** `DIVSD`
+- **Counted Python operations:** `x / y` or `y / x` for `CountedFloat`
+- **Not counted:** Division on non-CountedFloat, numpy division
+
+### FlopType.SQRT (`sqrt(x)`)
+- Relevant CPU instructions
+  - **ARM:** `FSQRT`
+  - **x86:** `SQRTSD`
+- **Counted Python operations:** `math.sqrt(x)` for `CountedFloat`
+- **Not counted:** `numpy.sqrt`, sqrt on non-CountedFloat
+
+### FlopType.CBRT (`cbrt(x)`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.cbrt(x)` for `CountedFloat`
+- **Not counted:** `numpy.cbrt`, cbrt on non-CountedFloat
+
+### FlopType.EXP (`e^x`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.exp(x)` for `CountedFloat`
+- **Not counted:** `math.exp(x)` on non-CountedFloat, `numpy.exp`, `math.expm1`, `math.e ** x`
+
+### FlopType.EXP2 (`2^x`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `2 ** x`, `pow(2, x)` or `math.exp2(x)` for `CountedFloat`
+- **Not counted:** `exp2` on non-CountedFloat, `numpy.exp2`
+
+### FlopType.EXP10 (`10^x`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `10 ** x`, `pow(10, x)` for `CountedFloat`
+- **Not counted:** `10 ** x` on non-CountedFloat
+
+### FlopType.LOG (`log(x)`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.log(x)` for `CountedFloat`
+- **Not counted:** `numpy.log`, log on non-CountedFloat
+
+### FlopType.LOG2 (`log2(x)`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.log2(x)` for `CountedFloat`
+- **Not counted:** `numpy.log2`, log2 on non-CountedFloat
+
+### FlopType.LOG10 (`log10(x)`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.log10(x)` for `CountedFloat`
+- **Not counted:** `numpy.log10`, log10 on non-CountedFloat
+
+### FlopType.POW (`x^y`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `x ** y`, `pow(x, y)` for `CountedFloat`
+- **Not counted:** `pow` on non-CountedFloat, `numpy.pow`
+
+### FlopType.SIN (`sin(x)`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.sin(x)` for `CountedFloat`
+- **Not counted:** `sin` on non-CountedFloat, `numpy.sin`
+
+### FlopType.COS (`cos(x)`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.cos(x)` for `CountedFloat`
+- **Not counted:** `cos` on non-CountedFloat, `numpy.cos`
+
+### FlopType.TAN (`tan(x)`)
+- Relevant CPU instructions
+  - **ARM:** (software)
+  - **x86:** (software)
+- **Counted Python operations:** `math.tan(x)` for `CountedFloat`
+- **Not counted:** `tan` on non-CountedFloat, `numpy.tan
